Thumbnail of Connet CoSF-D-YB-M Single Frequency Fiber Laser Module photo 1

Description

The Connet CoSF-D-YB-M Single Frequency Fiber Laser Module represents a breakthrough in laser technology, harnessing the power of Distributed Feedback Bragg Grating (DFB) to deliver a low-noise, stable single-frequency laser output. Boasting independent intellectual property rights, this module guarantees single longitudinal mode, linear polarization, and an impressively narrow linewidth.

CoSF-D-YB-M exhibits low phase and frequency noise and maintains low relative intensity noise (RIN). Connet employs cutting-edge packaging techniques to ensure DFB single frequency fiber lasers with remarkable wavelength stability.

Designed with a compact form factor and robust resistance to environmental interference, the CoSF-D-YB-M offers an output power exceeding 100mW. Built on ytterbium-doped fiber, this module features a narrow linewidth (<20kHz) and low phase noise, making it ideal for various applications across a broad wavelength range, including 1064nm, 1053nm, and 1083nm, with customization options available to meet specific requirements.

Connet CoSF-D-YB-M Single Frequency Fiber Laser Module

Visit the Connet Laser Technology Co., Ltd. Store

Specifications

Center Wavelength: 1010 nm
Output Power: 50 W
Output Mode: Single Frequency, Single Longitudinal Mode
Beam Quality (M^2): 1.05
Spectral Linewidth: 0.01 nm
Output Power Stability: 0.9% ~ 1.0%
Output Fiber Type: PMF
Output Fiber Length: 0.5 m
Interface: RS-485
Cooling: Air Cooled
Electrical Requirements: Other / Not Specified
Weight: <0.5 kg
Dimension: 145x100x25 mm
Power Supply: 12 VDC
Storage Temperature: -40 to +85 ℃
Operating Temperature: -20 to +50 ℃
Modulation Wavelength Range (typ.): >8 GHz
Modulation Frequency (linear): 10 kHz
PZT Wavelength Modulation: Optional
Wavelength Thermal Tuning: 0.6 nm
Output Isolation: 45 dB
Polarization Extinction Ratio (PER): 23 dB
Output Polarization: Linear
SMSR (50pm Resolution): 60 dB
RIN @10MHz: -140 dBc/Hz
RIN Peak: -110 dBc/Hz
RIN Peak Frequency: 1000 kHz

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Narrow linewidth <20kHz, typically <10kHz
  • Low phase noise and frequency noise
  • Low relative intensity noise (RIN)
  • Stable single frequency with single polarization output
  • No mode-hopping
  • Compact package dimensions: 145x100x25mm
  • High reliability

Applications

  • Distributed optical fiber sensing
  • Coherent LiDAR
  • Laser spectroscopy
  • Coherent communication
  • Gas absorption measurement
  • Cold atomic physics
  • Other scientific research

Frequently Asked Questions

Can the wavelength of the CoSF-D-YB-M Single Frequency Fiber Laser Module be customized?
Yes, the wavelength of the CoSF-D-YB-M Single Frequency Fiber Laser Module can be customized according to your requirements.
What are the applications of the CoSF-D-YB-M Single Frequency Fiber Laser Module?
The CoSF-D-YB-M Single Frequency Fiber Laser Module is typically used in distributed optical fiber sensing, coherent LiDAR, fiber optic hydrophone, laser spectroscopy, coherent communication, gas absorption measurement, cold atomic physics, and other scientific research applications.
What are the features of the CoSF-D-YB-M Single Frequency Fiber Laser Module?
The CoSF-D-YB-M Single Frequency Fiber Laser Module features narrow linewidth (<20kHz), low phase noise and frequency noise, low relative intensity noise (RIN), stable single frequency, single polarization output, and no mode-hopping. It also has a small sized package (145x100x25mm) and high reliability.
What is the CoSF-D-YB-M Single Frequency Fiber Laser Module?
The CoSF-D-YB-M Single Frequency Fiber Laser Module is a low-noise single frequency fiber laser module based on Distributed Feedback Bragg Grating (DFB) technology.
What is the output power of the CoSF-D-YB-M Single Frequency Fiber Laser Module?
The CoSF-D-YB-M Single Frequency Fiber Laser Module has an output power of more than 100mW.

Got more questions? Use the inquiry form to ask the supplier directly.
