Description

This cutting-edge fiber laser module, built upon Distributed Feedback Bragg Grating (DFB) technology, delivers exceptional performance with an emphasis on stability and low noise. Ideal for scientific research and advanced optical systems,

it provides a stable single-frequency laser output with single longitudinal mode, linear polarization, and an ultra-narrow linewidth.

CoSF-D-RS-YB-M integrates extra-cavity technology to significantly suppress relative intensity noise (RIN), ensuring minimal disruption to the resonant cavity of the single frequency fiber laser. With a compact design and strong resistance to environmental interference, this module boasts high reliability and fixed output power at 10mW, with the option for higher output power upon request.

The standard wavelength range includes 1064nm, 1053nm, 1083nm, and customization is available for wavelengths ranging from 1010nm to 1120nm.

Connet CoSF-D-RS-YB-M Low RIN Single Frequency Fiber Laser Module

Specifications

Center Wavelength: 1015 nm
Output Power: 0.01 W
Output Mode: Continuous Wave (CW), Single Longitudinal Mode
Beam Quality (M^2): 1.05
Spectral Linewidth: Not Specified
Output Power Stability: 0.9% ~ 1.0%
Output Fiber Type: PMF
Output Fiber Length: 0.5 m
Interface: RS-485
Cooling: Air Cooled
Electrical Requirements: Other / Not Specified
Output Polarization: Linear
Polarization Extinction Ratio (PER): 23 dB
Output Isolation: 45 dB
Wavelength Thermal Tuning: 0.6 nm
Modulation Frequency (linear): 10-90 kHz
Modulation Wavelength Range: >8 GHz
Operating Temperature: 0 to +60 ℃
Storage Temperature: -40 to +85 °C
Power Supply: 12 VDC
Dimension: 145x100x25 mm
Weight: <0.5 kg

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Ultra-narrow linewidth <20kHz, typically <10kHz
  • Low phase noise and frequency noise
  • Very low relative intensity noise (RIN)
  • Stable single frequency, single polarization output
  • No mode-hopping
  • Small-sized package: 145x100x25mm
  • High reliability

Applications

  • Distributed optical fiber sensing
  • Coherent LiDAR
  • Laser spectroscopy
  • Coherent communication
  • Gas absorption measurement
  • Cold atomic physics
  • Other scientific research

Frequently Asked Questions

Can the wavelength of the CoSF-D-RS-YB-M fiber laser module be customized?
Yes, the wavelength of the CoSF-D-RS-YB-M fiber laser module can be customized according to specific requirements.
What are the applications of the CoSF-D fiber laser module?
The CoSF-D fiber laser module can be used in distributed optical fiber sensing, coherent LiDAR, laser spectroscopy, coherent communication, gas absorption measurement, cold atomic physics, and other scientific research.
What are the features of the CoSF-D fiber laser module?
The CoSF-D fiber laser module has a narrow linewidth (<20kHz), low phase noise and frequency noise, very low relative intensity noise (RIN), stable single frequency and single polarization output, and no mode-hopping. It also has a small size, high reliability, and resistance to environmental interference.
What is the Connet CoSF-D fiber laser module?
The Connet CoSF-D is a low-noise single frequency fiber laser module based on Distributed Feedback Bragg Grating (DFB) technology.
What is the standard wavelength of the CoSF-D-RS-YB-M fiber laser module?
The standard wavelength of the CoSF-D-RS-YB-M fiber laser module is 1064nm, 1053nm, or 1083nm.
