Thumbnail of HASO FAST Wavefront Sensor photo 1
Thumbnail of HASO FAST Wavefront Sensor photo 2
Thumbnail of HASO FAST Wavefront Sensor photo 3

Description

Providing outstanding performance, the HASO FAST wavefront sensor is recommended for optical metrology, that needs high speed and high wavefront measurement accuracy, adaptive optics and free-space communication.

We offer a unique combination of expertise in high quality microlens production, software development and accurate wavefront sensor calibration at factory. This allows the HASO4 FAST to provide an unprecedented level of performance.

Ideal for measurements of fast changes in wavefronts, the HASO FAST Shack-Hartmann Wavefront Sensor, with a frame rate of 1 kHz, responds to all demanding applications.

This instrument is compatible with the Optical Engineer Companion metrology system.

HASO FAST Wavefront Sensor

Visit the Imagine Optic Store

Specifications

Wavelength Range: 400 – 900 nm
# Pixels (Width): Not Specified
# Pixels (Height): Not Specified
Lenslet Pitch: Not Specified
Wavefront Accuracy: <= lambda/30
Type: Shack Hartmann, Hartmann, Zernike, Other / Not specified
Repeatability: <Lambda/200 RMS
Microlens Number: 16 x 16
Absolute Accuracy: λ/100 RMS
Max. Acquisition Frequency: 1000 Hz
Pupil Size: 1.2 x 1.2 mm²

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Measurement of F/5 beams with λ/100 accuracy, including astigmatism and high-order aberrations
  • Patented technology for simultaneous and independent phase and intensity measurements
  • External trigger feature ensures accurate measurement time
  • Low latency of 2.2ms for high performance adaptive optics
  • Only 1 nW power required on sensor at 1kHz

Applications

  • Quantify the optical system’s aberrations
  • Align the system to ensure that it performs at its best
  • Drive a deformable mirror to do high frame rate adaptive optics
  • Quantify the transitional regime of active optical elements such as variable focal length lenses
  • Verify that the optics comply with specifications
  • Directly measure the optical system’s wavelength dependency
  • Quantify the pointing stability of high frame rate laser
  • Check whether the optical mount overly distorts the optics

Frequently Asked Questions

What is the recommended use for the HASO FAST wavefront sensor?
The HASO FAST wavefront sensor is recommended for optical metrology, adaptive optics, and free-space communication that require high speed and high wavefront measurement accuracy.
What is the frame rate of the HASO FAST wavefront sensor?
The HASO FAST wavefront sensor has a frame rate of 1 kHz.
What are the features of the HASO FAST wavefront sensor?
The features of the HASO FAST wavefront sensor include measurement of F/5 beams with λ/100 accuracy, simultaneous and independent phase and intensity measurements, an external trigger feature for accurate measurement time, and low latency of 2.2ms for high-performance adaptive optics.
What are some applications of the HASO FAST wavefront sensor?
Some applications of the HASO FAST wavefront sensor include quantifying the optical system's aberrations, aligning the system for optimal performance, driving a deformable mirror for high frame rate adaptive optics, and measuring the pointing stability of high frame rate lasers.
What are the operating specifications of the HASO FAST wavefront sensor?
The operating specifications of the HASO FAST wavefront sensor include an aperture dimension of 1.2 x 1.2 mm², 16 x 16 microlenses, a maximum acquisition frequency of 1.25 kHz, a calibrated wavelength range of 400 - 900 nm, a minimum power requirement of 0.15 nW, and an external trigger TTL signal.

Got more questions? Use the inquiry form to ask the supplier directly.
