SkyAMP 1030nm-LP Ultracompact Ultrafast Single Mode Laser Amplifier Booster
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Canada
-
Sold by:
-
On FindLight:
since 2019
Description
The SkyAMP - 1030 nm - LP is a state-of-the-art laser amplifier designed to deliver exceptional performance in a compact and rugged form factor. This cutting-edge device is engineered for easy in-line integration, making it an ideal choice for seamless incorporation into existing systems. With its robust construction, the SkyAMP ensures reliable operation even in demanding environments, providing a dependable solution for various applications.
One of the standout features of the SkyAMP is its water-cooled design, which significantly enhances its operational efficiency and longevity. The water cooling system ensures optimal thermal management, allowing the device to maintain peak performance under continuous use. This feature, combined with the standard SMA pump port, facilitates straightforward connectivity and operation, ensuring that the SkyAMP meets the rigorous demands of modern laser applications.
The SkyAMP - 1030 nm - LP is equipped with a standard MM pump fiber input, offering a versatile and high-performance solution for laser amplification. With a focus on delivering superior beam quality, the SkyAMP ensures that the output remains consistent and precise, thanks to its single-mode laser design. This advanced technology is tailored to meet the needs of professionals seeking reliable and high-quality laser amplification.
SkyAMP 1030nm-LP Ultracompact Ultrafast Single Mode Laser Amplifier Booster
Specifications |
|
|---|---|
| Center Wavelength: | 1030 nm |
| Repetition Rate: | 1 – 80000 kHz |
| Pulse Energy: | 1 mJ |
| Energy Stability (RMS): | 1 % |
| Pulse Duration: | 500 fs |
| Polarization: | Unspecified |
| Spatial Mode (M^2): | <1.3 |
| Amplification Scheme: | Not Specified |
| Average Output Power: | up to 30 W |
| Average Input Power: | as low as 0.1 W |
| Dimensions: | 270 X 220 X 50 mm |
| Output Beam Structure: | Single Mode |
| Input Port Connector: | SMA |
| Cooling: | Water |
Features
- Standard MM Pump Fiber Input: Designed for compatibility with standard multimode pump fibers, ensuring efficient power delivery.
- Compact and Rugged Design: Built to withstand demanding environments while maintaining a small footprint.
- Easy In-line Integration: Simplifies the process of incorporating the amplifier into existing systems.
- Water Cooled: Features water cooling to maintain optimal performance and prevent overheating.
- Standard SMA Pump Port: Equipped with a standard SMA port for easy connection and integration.
- 1.03 Micron Amplifier/Booster: Operates at a center wavelength of 1030 nm, ideal for a wide range of applications.
- Single Mode Laser: Ensures high beam quality with an output M2 limited by input M2.
- Output Power: Capable of delivering up to 80 W, depending on input power.
- Input Wavelength: Accepts input wavelengths ranging from 1029 to 1031 nm.
- Output Wavelength: Also operates within a wavelength range of 1029 to 1031 nm for optimal performance.
- Port Return Loss: Offers a port return loss greater than 40 dB, minimizing feedback and ensuring stable operation.
- Fiber Type: Available in 105/125 or 200/220 loose tube configurations with a core/clad diameter NA of 0.22.
- Water Cooling Tube Fittings: Compatible with 1/4" tubing, facilitating easy setup and maintenance.
- Gain: Provides a gain range from 0 to 40 dB, adaptable to varying input power levels.
Applications
- Industrial Material Processing: Enables stable, high-power amplification for precision cutting, welding, and marking.
- Scientific Research: Ideal for laboratory-based high-resolution spectroscopy and laser experiments.
- Fiber Laser Systems: Serves as an efficient booster stage in high-power laser setups.
- Nonlinear Optics: Supports generation of higher harmonics and other nonlinear effects.
