AOFemto 515nm 1W DPSS Laser
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2014
Description
The next product in Advanced Optowave’s ultra short-pulsed laser product line is the AOFemto™ Series. Like the AOPico™ Series, the AOFemto™ is also a diode-pumped solid-state Hybrid master-oscillator power-amplifier, the main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.
Our complete ultra short pulsed laser product line is built on a common platform and we have designed it to use components that we also use in our nanosecond product line, components that have a solid track record for being highly reliable and stable. Because of the common components utilization, we can provide you, the customer, with a much more cost-effective products.
Ultrashort pulse lasers have the unique ability to machine materials with little or no thermal damage, and the ability to machine materials that have not previously been able to be process with lasers.
AOFemto 515nm 1W DPSS Laser
Specifications |
|
|---|---|
| Avg. Power: | 1 W |
| Wavelength: | 515 nm |
| Repetition Rate: | 1 – 100 kHz |
| Spatial Mode (M^2): | 1.3 |
| Pulse Duration: | 0.0008 ns |
| Pulse-to-Pulse Stability (RMS): | 2 % |
| Cooling: | Water-to-Water |
| Energy: | 20 µJ |
| Repetition Rate: | Single Shot to 1000 kHz |
| Beam Quality (M2): | <1.3 |
| Beam Roundness: | >85% |
| Beam Diameter: | 2.0 mm |
| Point Stability: | <20 µrad/ºC |
| Polarization Ratio: | 100:1 Linear, Vertical |
| Polarization Ratio: | 100:1 Linear, Horizontal |
| Pulse-to-Pulse Stability: | <2% RMS |
| Operational Temperature Range: | 15 to 30 ºC |
| Storage Temperature Range: | -20 to 50 ºC |
| Input Voltage: | 90 to 260 VAC |
Features
- Lowest Cost of Ownership: Benefit from the most economical solution in the industry.
- Excellent Beam Quality: M2 < 1.3 for superior precision.
- Versatile Wavelength Options: Available in IR, Green, and UV.
- High Average Power: Up to 15W for demanding applications.
- Ultra-Short Pulse Durations: Less than 800 femtoseconds for high-speed processing.
- Reliable Design: Engineered for durability and consistent performance.
- Burst Mode Option: Enhanced flexibility for various applications.
- Advanced Applications: Ideal for injector drilling, medical device manufacturing, polymer processing/machining, semiconductor/PV processing/wafer scribing, and high-precision micro-machining.
- Brittle Material Processing: Effective for cutting, drilling, dicing, and sub-surface marking.
- Compliance: Meets CDRH, ROHS, and CE standards.
- Robust Communication: RS-232 interface for seamless integration.
- Efficient Cooling: Water-cooled system for optimal thermal management.
- Wide Operational Range: Functions effectively in temperatures from 15 to 30°C and humidity levels from 20 to 80% (non-condensing).
- Convenient Storage Conditions: Storage temperature range from -20 to 50°C.
- Flexible Power Input: Compatible with 90 to 260 VAC, 50 or 60 Hz.
Applications
- Injector Drilling
- Medical Device Manufacturing
- Polymer Processing/Machining
- Semiconductor/PV Processing/Wafer Scribing
- High-Precision, High-Speed Micro-machining
- Brittle Material Cutting, Drilling, Dicing & Sub-Surface Marking
Frequently Asked Questions
The AOFemto™ Series laser is used for high-precision, high-speed micro-machining, brittle material cutting, drilling, dicing, and sub-surface marking.
The AOFemto™ Series laser has an average power of up to 15 watts in the IR and 7.5 watts in the green.
Advanced Optowave Corporation offers a limited warranty for the AOFemto™ Series laser.
The AOFemto™ Series laser has a pulse duration of less than 800 femtoseconds.
The AOFemto™ Series laser has an excellent beam quality of M2 <1.3.
