Description

The next product in Advanced Optowave’s ultra short-pulsed laser product line is the AOFemto™ Series. Like the AOPico™ Series, the AOFemto™ is also a diode-pumped solid-state Hybrid master-oscillator power-amplifier, the main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.

Our complete ultra short pulsed laser product line is built on a common platform and we have designed it to use components that we also use in our nanosecond product line, components that have a solid track record for being highly reliable and stable. Because of the common components utilization, we can provide you, the customer, with a much more cost-effective products.

Ultrashort pulse lasers have the unique ability to machine materials with little or no thermal damage, and the ability to machine materials that have not previously been able to be process with lasers.

AOFemto 515nm 10W DPSS Laser

Visit the Advanced Optowave Corporation Store

Specifications

Avg. Power: 10 W
Wavelength: 515 nm
Repetition Rate: 100 – 200 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.0008 ns
Pulse-to-Pulse Stability (RMS): 2 %
Cooling: Water-to-Water
Average Power: Up to 15W
Wavelength (nm): 515
Average Power (Watts): 2
Average Power (Watts): 20
Energy (µJ): 20
Energy (µJ): 100
Repetition Rate (kHz): Single Shot to 1000
Beam Roundness (%): >85
Beam Diameter (mm): 2.0
Beam Divergence (mRad): <1.3
Point Stability (µrad/ºC): <20
Polarization Ratio: 100:1 Linear, Vertical
Pulse-to-Pulse Stability (% RMS): <2
Average Power Stability (% Over 12 Hours): <3
Operational Temperature Range (ºC): 15 to 30
Storage Temperature Range (ºC): -20 to 50
Input Voltage (VAC): 90 to 260

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Lowest Cost of Ownership in the Industry: Designed to provide exceptional value and reduce operational expenses.
  • Excellent Beam Quality: M2 < 1.3, ensuring precision in applications.
  • Multiple Wavelength Options: Available in IR, Green, and UV to suit diverse industrial needs.
  • High Average Power: Delivers up to 15W, supporting high-speed operations.
  • Ultra-Short Pulse Durations: Pulse durations of less than 800 fs for precision micro-machining.
  • Highly Reliable Design: Engineered for durability and consistent performance.
  • Burst Mode Option: Enhances flexibility and control in various applications.
  • Versatile Applications: Ideal for injector drilling, medical device manufacturing, polymer processing, semiconductor processing, and more.
  • Compliance and Safety: Meets CDRH, ROHS, and CE standards.

Applications

  • Injector Drilling
  • Medical Device Manufacturing
  • Polymer Processing/Machining
  • Semiconductor/PV Processing/Wafer Scribing
  • High-Precision, High-Speed Micro-machining
  • Brittle Material Cutting, Drilling, Dicing & Sub-Surface Marking

Frequently Asked Questions

What is the AOFemto™ Series laser used for?
The AOFemto™ Series laser is used for high-precision, high-speed micro-machining, brittle material cutting, drilling, dicing, and sub-surface marking.
What is the maximum power output of the AOFemto™ Series laser?
The AOFemto™ Series laser can deliver powers up to 15 watts in the IR and 7.5 watts in the green.
What is the warranty offered by Advanced Optowave Corporation for the AOFemto™ Series laser?
Advanced Optowave Corporation offers a limited warranty for the AOFemto™ Series laser.
What is the pulse duration of the AOFemto™ Series laser?
The AOFemto™ Series laser has a pulse duration of less than 800 femtoseconds.
What is the beam quality of the AOFemto™ Series laser?
The AOFemto™ Series laser has an excellent beam quality of M2 <1.3.
