Description

The next product in Advanced Optowave’s ultra short-pulsed laser product line is the AOFemto™ Series. Like the AOPico™ Series, the AOFemto™ is also a diode-pumped solid-state Hybrid master-oscillator power-amplifier, the main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.

Our complete ultra short pulsed laser product line is built on a common platform and we have designed it to use components that we also use in our nanosecond product line, components that have a solid track record for being highly reliable and stable. Because of the common components utilization, we can provide you, the customer, with a much more cost-effective products.

Ultrashort pulse lasers have the unique ability to machine materials with little or no thermal damage, and the ability to machine materials that have not previously been able to be process with lasers.

AOFemto 1030nm 10W DPSS Laser

Specifications

Avg. Power: 10 W
Wavelength: 1030 nm
Repetition Rate: 1 – 100 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.0008 ns
Pulse-to-Pulse Stability (RMS): 2 %
Cooling: Water-to-Water
Energy (µJ): 20
Repetition Rate (kHz): Single Shot to 1000
Beam Roundness (%): >85
Beam Diameter (mm): 2.0
Beam Divergence (mRad): <1.3
Point Stability (µrad/ºC): <20
Polarization Ratio: 100:1 Linear, Vertical
Pulse-to-Pulse Stability (% RMS): <2
Operational Temperature Range (ºC): 15 to 30
Storage Temperature Range (ºC): -20 to 50
Input Voltage (VAC): 90 to 260
Line Frequency (Hz): 50 or 60
Laser Head Dimensions: 27 x 15 x 7 in (686 x 381 x 179 mm)
Laser Head Weight: 70 lbs (32 kg)
Laser Controller Dimensions: 19 x 17 x 7 in (482 x 432 x 178 mm)
Laser Controller Weight: 30 lbs (13.6 kg)
Umbilical Length: 100 in (2.5 m)

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Industry-Leading Cost Efficiency: The AOFemto™ Series offers the lowest cost of ownership in the industry, making it a cost-effective solution for various industrial applications.
  • Superior Beam Quality: Achieve excellent beam quality with an M2 value of less than 1.3, ensuring precision and accuracy in micro-machining tasks.
  • Versatile Wavelength Options: Available in IR, Green, and UV wavelengths to suit diverse application needs, including semiconductor processing and medical device manufacturing.
  • High Power Output: Delivers up to 15W average power, enabling high-speed and high-precision operations.
  • Ultra-Short Pulse Durations: Features pulse durations of less than 800 femtoseconds, ideal for intricate and detailed machining processes.
  • Robust and Reliable Design: Built with a highly reliable design to withstand demanding industrial environments.
  • Burst Mode Capability: Includes a burst mode option for enhanced performance in specific applications.
  • Wide Range of Applications: Suitable for injector drilling, polymer processing, wafer scribing, brittle material cutting, drilling, dicing, and sub-surface marking.
  • Compliance and Safety Standards: Meets CDRH, ROHS, and CE compliance standards, ensuring safe and reliable operation.

Applications

  • Injector Drilling
  • Medical Device Manufacturing
  • Polymer Processing/Machining
  • Semiconductor/PV Processing/Wafer Scribing
  • High-Precision, High-Speed Micro-machining
  • Brittle Material Cutting, Drilling, Dicing & Sub-Surface Marking

Frequently Asked Questions

What are some applications of the AOFemto™ Series?
Some applications of the AOFemto™ Series include injector drilling, medical device manufacturing, polymer processing/machining, semiconductor/PV processing/wafer scribing, high-precision, high-speed micro-machining, and brittle material cutting, drilling, dicing & sub-surface marking.
What is the main difference between the AOPico™ Series and the AOFemto™ Series?
The main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.
What is the AOFemto™ Series?
The AOFemto™ Series is the next product in Advanced Optowave’s ultra short-pulsed laser product line.
What is the warranty offered for the AOFemto™ Series?
Advanced Optowave Corporation offers a limited warranty for the AOFemto™ Series.
What is the cost of ownership for the AOFemto™ Series?
The AOFemto™ Series has the lowest cost of ownership in the industry.

Got more questions? Use the inquiry form to ask the supplier directly.
