Thumbnail of CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module photo 1

Description

The CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module by Connet is a high-performance laser module based on Distributed Feedback Bragg Grating (DFB) technology. It offers stable single-frequency, single-polarization output with low phase noise, frequency noise, and relative intensity noise (RIN).

With its narrow linewidth (<15kHz) and small-sized package, it is highly reliable and suitable for various scientific research and industrial applications.

CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module

Visit the Connet Laser Technology Co., Ltd. Store

Specifications

Center Wavelength: 1530 nm
Output Power: 0.1 W
Output Mode: Continuous Wave (CW), Single Frequency, Single Longitudinal Mode
Beam Quality (M^2): 1.05
Spectral Linewidth: Not Specified
Output Power Stability: </= 0.1%
Output Fiber Type: PMF
Output Fiber Length: 0.5 m
Interface: Other / Not-specified
Cooling: Other
Electrical Requirements: Other / Not Specified
Optical Connector: FC/APC
Power Supply: 12 VDC
Linewidth: 10 KHz
Polarization Extinction Ratio (PER): 25 dB
Output Isolation: 50 dB
Wavelength Thermal Tuning: 0.8 nm
Modulation Frequency (linear): 10 kHz
Modulation Wavelength Range: >8 GHz

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Narrow linewidth (<15kHz, typically <10kHz)
  • Low phase noise and frequency noise
  • Very low relative intensity noise (RIN)
  • Stable single frequency, single polarization output
  • No mode-hopping
  • Small-sized package (145x100x25mm)
  • High reliability

Applications

  • Distributed optical fiber sensing
  • Coherent LiDAR
  • Fiber optic hydrophone
  • Laser spectroscopy
  • Coherent communication
  • Gas absorption measurement
  • Cold atomic physics
  • Other scientific research

Frequently Asked Questions

What are the applications of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module?
The applications of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module include distributed optical fiber sensing, coherent LiDAR, fiber optic hydrophone, laser spectroscopy, coherent communication, gas absorption measurement, cold atomic physics, and other scientific research.
What are the features of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module?
The features of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module include narrow linewidth (<15kHz, typically <10kHz), low phase noise and frequency noise, very low relative intensity noise (RIN), stable single frequency, single polarization output, no mode-hopping, small-sized package (145x100x25mm), and high reliability.
What are the specifications of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module?
The specifications of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module include center wavelength, output power, laser output, beam quality, linewidth, RIN peak frequency and level, phase noise, SMSR, output polarization, PER, output power stability, output isolation, wavelength thermal tuning, PZT wavelength modulation, operating temperature, storage temperature, power supply, communication interface, output fiber type and length, optical connector, dimension, and weight.
What is the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module?
The CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module is a high-performance laser module based on Distributed Feedback Bragg Grating (DFB) technology that offers stable single-frequency, single-polarization output with low phase noise, frequency noise, and relative intensity noise (RIN).
What is the wavelength range of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module?
The standard wavelength of the CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module is 1551.12nm, and the optional wavelength range is 1530-1570nm, such as the standard wavelength under the ITU framework. Other wavelengths can be customized according to requirements.
