Description
The Everfoton 4000W - 6000W CW Fiber Lasers are ideal for metal cutting, welding, and drilling applications. With high wall-plug efficiency, multi-stage anti-back reflection protection, and a compact design, these lasers offer excellent performance and easy integration into existing systems.
4000W CW Fiber Laser FFSC-4000F
Specifications
| Center Wavelength: | 1080 nm |
|---|---|
| Output Power: | 4000 W |
| Output Mode: | Continuous Wave (CW), Modulated |
| Beam Quality (M^2): | 110 |
| Spectral Linewidth: | 4 nm |
| Output Power Stability: | > 5% |
| Output Fiber Type: | Other / Non-specified |
| Output Fiber Length: | 20 m |
| Interface: | Other / Not-specified |
| Cooling: | Water Cooled (closed loop), Water Cooled (open loop) |
| Electrical Requirements: | 380V - 50Hz, 400V - 50Hz |
| Polarization State: | Random |
| Output Power Tunability: | 10-100% |
| Output Power Instability 25℃ (%): | ＜ 2 (2 hours) |
| Modulation Frequency: | 5 kHz |
| Red Laser Power: | > 120 μW |
| Output Type: | QBH/LOE |
| Core Diameter: | 800 um |
| Minimum Bending Radius: | 200 mm |
| Max Power Consumption: | 12 kW |
| Control Mode: | RS232/AD/Ethernet |
Download Data Sheet
Features
- High wall-plug efficiency
- Multi-stages anti-back reflection protections
- Flat top beam for cladding application
- Compact design with small footprint
Applications
- Cladding
- Quenching
- Surface heat treatment
Frequently Asked Questions
What are the applications for the Everfoton 4000W - 6000W CW Fiber Lasers?
The applications for these lasers include metal cutting, welding, and drilling.
What are the features of the Everfoton 4000W - 6000W CW Fiber Lasers?
The lasers have high wall-plug efficiency, multi-stage anti-back reflection protection, a flat top beam for cladding application, and a compact design with a small footprint.
Can these lasers be easily integrated into existing systems?
Yes, these lasers offer easy integration into existing systems.
What is the power output of the Everfoton 4000W - 6000W CW Fiber Lasers?
The power output ranges from 4000W to 6000W.
Where can I find more information about the Everfoton 4000W - 6000W CW Fiber Lasers?
You can find more information, including the datasheet, by clicking on the provided link to buy the product.
