Specifications

Center Wavelength: 1080 nm
Output Power: 4000 W
Output Mode: Continuous Wave (CW), Modulated
Beam Quality (M^2): 4
Spectral Linewidth: 4 nm
Output Power Stability: > 5%
Output Fiber Type: Other / Non-specified
Output Fiber Length: 20 m
Interface: Other / Not-specified
Cooling: Water Cooled (closed loop), Water Cooled (open loop)
Electrical Requirements: 380V - 50Hz, 400V - 50Hz, Other / Not Specified
Polarization State: Random
Output Power Tunability: 10-100 %
Output Power Instability 25℃: < 2 (2 hours) %
Modulation Frequency: 5 kHz
Red Laser Power: > 200 μW
Output Type: QBH
Core Diameter: 50/100 μm
Minimum Bending Radius: 200 mm
Max Power Consumption: 12 kW
Control Mode: RS232/AD/Ethernet
Document icon Download Data Sheet Download icon

Features



  • High wall-plug efficiency

  • Multi-stages anti-back reflection protections

  • Flat top energy distribution

  • Less spatter in welding

  • Maintaining thin plate cutting speed and medium and thick plate cutting quality

  • 50μm/100μm high brightness output option

  • Larger beam spot option for excellent quality cutting of thick metals


Applications



  • Sheet metal machining-cutting

  • Welding
