Specifications

Center Wavelength: 1080 nm
Output Power: 12000 W
Output Mode: Continuous Wave (CW), Modulated
Beam Quality (M^2): 4
Spectral Linewidth: 4 nm
Output Power Stability: > 5%
Output Fiber Type: Other / Non-specified
Output Fiber Length: 25 m
Interface: Other / Not-specified
Cooling: Water Cooled (closed loop), Water Cooled (open loop)
Electrical Requirements: 380V - 50Hz, 400V - 50Hz, Other / Not Specified
Polarization State: Random
Output Power Tunability: 10-100 %
Output Power Instability 25℃ (%): < 2 (2 hours)
Modulation Frequency: 5 kHz
Red Laser Power: > 200 μW
Output Type: QD/Q+/LOE
Core Diameter: 100 um
Minimum Bending Radius: 200 mm
Max Power Consumption: 36 kW
Control Mode: RS232/AD/Ethernet
Document icon Download Data Sheet Download icon

Features

  • High wall-plug efficiency
  • Flat top beam options
  • Multi-stages anti-back reflection protections
  • Less spatter in welding
  • Compact design with small footprint

Applications

  • Sheet metal machining-cutting
  • Welding
