1250M Series II
Description
With a 1000 mm focal length, this spectrometer is ideal for applications when extremely low stray light levels are required, such as in Raman fluorescence excitation or when ultra high resolution is needed for emission structure analysis. A large mechanical range allows high density gratings to be utilized at a longer wavelength for maximum resolution potential – a 1200 g/mm grating can be scanned to 1500 nm, with .008 nm resolution.
The M Series has long been a proven family of research-grade spectrometers, offering a degree of system automation and versatility not found in any comparable focal length spectrometer. The new Series II product line provides the reliability and unchallenged resolution that has come to be associated with M Series spectrometers, with improved features including high speed USB 2.0 compatibility, complete library of interchangeable gratings, and compatibility with HORIBA Scientific’s Synapse™ CCDs, full line of single channel detectors, PMTs and accessories.
1250M Series II
Specifications |
|
|---|---|
| Monochromator Type: | Czerny-Turner |
| Effective Focal Length: | 1250 mm |
| Diffraction Grating: | 1200 lines/mm |
| Grating Blaze Wavelength: | 435 nm |
| Spectral Range: | 0-1500nm |
| Linear Dispersion (Avg): | 0.65 nm/mm |
| Spectral Resolution (Avg): | 0.006 nm |
Features
Superb resolution
High throughput
Unequalled repeatability
Four ports capability
High precision slit for the best resolution repeatability
Compatible with most CCDs
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
The resolution at the exit slit with PMT for the 1250M Series II spectrometer is 0.006 nm.
The spectral range of the 1250M Series II spectrometer is 0 - 1500 nm.
The 1250M Series II spectrometer has a focal length of 1.25 meters.
The weight of the 1250M Series II spectrometer is 72.7 kg (160 lb).
The 1250M Series II spectrometer has a USB 2.0 computer interface.
