Designed for precision laser beam manipulation, the OPTOMAN PCX-F700-UVFS-25.4-ET2.0-AR548-AR548 plano-convex lens combines premium UV fused silica with advanced ion beam sputtered anti-reflection coatings to deliver exceptional optical performance at 1030 nm. Its long 700 mm focal length enables controlled beam focusing over extended working distances while maintaining excellent wavefront quality and transmission efficiency.

Manufactured to tight optical tolerances, this lens is an excellent choice for ultrafast lasers, high-power beam delivery, precision metrology, and scientific instrumentation where consistent optical performance and long-term reliability are essential. The durable coating technology minimizes reflection losses while supporting demanding industrial and research environments.

PCX-F700-UVFS-25.4-ET2.0-AR548-AR548 Plano-Convex UV Fused Silica Lens

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 700 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F700-UVFS-25.4-ET2.0-AR548-AR548
FindLight SKU: FL-24739

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F700-UVFS-25.4-ET2.0-AR548-AR548
  • Plano-convex optical design optimized for focusing collimated laser beams
  • UV-grade fused silica (JGS1/UVFS) substrate provides excellent transmission and thermal stability
  • 700 mm focal length suitable for long working distance beam delivery and precision optical systems
  • Dual-sided IBS anti-reflection coating with reflectance below 0.1% at 1030 nm for maximum optical efficiency
  •  25.4 mm precision diameter for compatibility with standard optical mounts
  • High-quality optical surfaces with 20-10 scratch-dig and λ/6 surface irregularity over the clear aperture
  • Centration error below 3 arcminutes for improved beam quality and alignment accuracy
  • Designed for ultrafast laser applications with high laser damage resistance

Applications

  • Ultrafast femtosecond and picosecond laser systems
  • Industrial laser material processing
  • Laser beam focusing and beam delivery
  • Precision scientific instrumentation
  • Optical laboratories and photonics research
  • Laser micromachining and microfabrication
  • High-power laser integration
  • OEM laser equipment and custom optical assemblies

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What type of lens is the PCX-F700-UVFS-25.4-ET2.0-AR548-AR548?
It is a precision plano-convex lens designed for efficiently focusing collimated laser beams while maintaining excellent optical performance in ultrafast laser systems.
Why is UV fused silica used for this lens?
UV fused silica offers outstanding transmission, low thermal expansion, excellent resistance to laser-induced damage, and stable optical performance across demanding laser applications.
What wavelength is the AR coating optimized for?
The dual-sided IBS anti-reflection coating is optimized for 1030 nm, reducing surface reflections to below 0.1% and maximizing transmission efficiency.
Which applications benefit from a 700 mm focal length?
A long focal length is well suited for applications requiring extended working distances, gentle beam convergence, precision beam delivery, laser measurement systems, and research setups.
Can this lens be used in high-power ultrafast laser systems?
Yes. Its UV fused silica substrate, durable IBS coatings, precision manufacturing, and high laser damage resistance make it well suited for high-power femtosecond and picosecond laser applications.
