Description

The OPTOMAN PCX-F200-UVFS-25.4-ET2.0-AR784-AR784 is a premium plano-convex laser lens engineered for demanding ultrafast laser applications operating at 515 nm. Manufactured from high-quality UV fused silica (JGS1), this precision optical component features advanced ion beam sputtered (IBS) anti-reflective coatings that deliver exceptionally low residual reflectance below 0.1%, maximizing optical throughput while minimizing thermal losses.

With a 200 mm focal length, λ/6 surface irregularity, 20-10 scratch-dig surface quality, and high laser-induced damage threshold, this lens provides outstanding beam focusing performance for femtosecond and picosecond laser systems used in industrial processing, precision manufacturing, and scientific research.

PCX-F200-UVFS-25.4-ET2.0-AR784-AR784 Plano-Convex UV Fused Silica Lens 200 mm

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 200 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F200-UVFS-25.4-ET2.0-AR784-AR784
FindLight SKU: FL-24743

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F200-UVFS-25.4-ET2.0-AR784-AR784
  • Plano-convex UV fused silica (JGS1) lens optimized for 515 nm laser wavelength
  • Precision 200 mm focal length with ±1% tolerance
  • 25.4 mm diameter with >80% clear aperture
  • IBS anti-reflective coatings on both surfaces with <0.1% reflectance at 515 nm
  • High laser-induced damage threshold suitable for ultrafast femtosecond and picosecond lasers
  • λ/6 surface irregularity over the clear aperture for excellent wavefront quality
  • 20-10 scratch-dig surface quality for low scatter and high optical performance
  • Low absorption coating design minimizes thermal effects during high-power operation
  • Laser-engraved orientation markings simplify installation and alignment

Applications

  • Frequency-doubled Yb:YAG laser systems (515 nm)
  • Ultrafast laser beam focusing
  • Precision laser micromachining
  • Semiconductor and electronics manufacturing
  • Medical laser instrumentation
  • Scientific and laboratory optical setups
  • Nonlinear optics experiments
  • Laser materials processing
  • High-precision metrology
  • Research and development photonics systems

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What laser wavelength is this lens designed for?
This lens is specifically optimized for 515 nm laser systems and features IBS anti-reflective coatings that reduce surface reflections to below 0.1% at this wavelength, maximizing transmission efficiency.
Why is UV fused silica used for this lens?
UV fused silica (JGS1) offers excellent optical homogeneity, low absorption, superior thermal stability, and a high laser damage threshold, making it ideal for demanding ultrafast laser applications and precision beam delivery.
What types of laser systems is this lens compatible with?
The lens is well suited for frequency-doubled Yb-based ultrafast laser platforms, including femtosecond and picosecond systems used in micromachining, precision manufacturing, and advanced scientific research.
What benefits do IBS anti-reflective coatings provide?
Ion Beam Sputtered coatings deliver extremely low optical losses, excellent environmental durability, high transmission, and outstanding resistance to high laser power, making them ideal for long-term industrial and research applications.
Is this lens suitable for high-power ultrafast lasers?
Yes. The combination of premium UV fused silica, precision optical fabrication, and high-LIDT IBS coatings makes this lens an excellent choice for high-peak-power femtosecond and picosecond laser systems operating at 515 nm.

Got more questions? Use the inquiry form to ask the supplier directly.
