Description

The OPTOMAN PCX-F175-UVFS-25.4-ET2.0-AR784-AR784 is a precision plano-convex lens manufactured from premium UV-grade fused silica (JGS1) and optimized for demanding ultrafast laser applications operating at 515 nm. Featuring advanced ion beam sputtered (IBS) anti-reflective coatings on both surfaces, the lens delivers exceptionally low reflectance, high transmission, minimal absorption, and excellent laser-induced damage resistance for femtosecond and picosecond laser systems.

With a 175 mm focal length, 25.4 mm diameter, superior surface quality, and excellent wavefront performance, it is an ideal choice for beam focusing, imaging, and laser processing applications where optical efficiency and long-term stability are critical.

PCX-F175-UVFS-25.4-ET2.0-AR784-AR784 Plano-Convex UV Fused Silica Lens 175 mm

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 175 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F175-UVFS-25.4-ET2.0-AR784-AR784
FindLight SKU: FL-24740

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F175-UVFS-25.4-ET2.0-AR784-AR784
  • Plano-convex spherical lens with 175 mm focal length
  • UV-grade fused silica (JGS1) substrate for outstanding UV-visible transmission
  • Precision IBS anti-reflective coatings optimized for 515 nm
  • Surface reflectance below 0.1% for maximum optical throughput
  • Designed for ultrafast femtosecond and picosecond laser systems
  • High laser-induced damage threshold for high-power laser operation
  • 25.4 mm diameter with 2.0 mm edge thickness
  • Surface quality of 20-10 scratch-dig and surface irregularity better than λ/6
  • Excellent beam quality preservation with low optical losses and minimal pulse distortion

Applications

  • Ultrafast laser beam focusing
  • Precision laser micromachining
  • Semiconductor and electronics manufacturing
  • Scientific spectroscopy and laboratory research
  • Biomedical laser instrumentation
  • Nonlinear optics experiments
  • Optical imaging systems
  • Beam delivery and conditioning
  • Second-harmonic Yb:YAG laser systems operating at 515 nm
  • Industrial laser processing equipment

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the PCX-F175-UVFS-25.4-ET2.0-AR784-AR784 designed for?
This plano-convex lens is designed for precision beam focusing and optical beam manipulation in ultrafast laser systems operating at 515 nm, where high transmission and low optical losses are essential.
Why is UV fused silica used for this lens?
UV-grade fused silica provides excellent transmission, low thermal expansion, outstanding optical homogeneity, and high resistance to laser-induced damage, making it ideal for demanding laser applications.
What advantages do IBS anti-reflective coatings provide?
Ion Beam Sputtered coatings offer extremely low reflectance, excellent environmental durability, low absorption, and stable long-term optical performance compared with conventional coating technologies.
Can this lens be used with femtosecond and picosecond lasers?
Yes. The lens is specifically engineered for ultrafast laser applications and is optimized to preserve beam quality while handling the high peak intensities produced by femtosecond and picosecond laser sources.
Which industries commonly use this optical lens?
This lens is widely used in laser materials processing, semiconductor manufacturing, biomedical photonics, scientific research, precision metrology, nonlinear optics, and advanced industrial laser systems.

Got more questions? Use the inquiry form to ask the supplier directly.
