Description

The OPTOMAN PCX-F150-UVFS-25.4-ET2.0-AR784-AR784 is a premium UV fused silica plano-convex (PCX) lens engineered for demanding ultrafast laser applications operating at 515 nm. Manufactured from high-purity UV grade fused silica (JGS1), it combines exceptional optical quality with ion beam sputtered (IBS) anti-reflection coatings that deliver reflectance below 0.1% per surface for maximum transmission and minimal optical losses.

Designed with a 150 mm focal length, λ/6 transmitted wavefront quality, 20-10 scratch-dig surface finish, and an estimated laser-induced damage threshold exceeding 0.25 J/cm² (515 nm, 500 fs, 10 kHz), this precision lens preserves beam quality while handling high peak-power femtosecond and picosecond laser pulses. It is an excellent choice for beam delivery, focusing, imaging, and laser materials processing systems requiring outstanding stability, low absorption, and long-term reliability.

PCX-F150-UVFS-25.4-ET2.0-AR784-AR784 UV Fused Silica Plano-Convex Lens 150 mm

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 150 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F150-UVFS-25.4-ET2.0-AR784-AR784
FindLight SKU: FL-24741

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F150-UVFS-25.4-ET2.0-AR784-AR784
  • UV grade fused silica (JGS1) substrate for superior transmission and thermal stability
  • 25.4 mm diameter with 150 mm focal length for precision beam focusing
  • IBS anti-reflection coating optimized for 515 nm with reflectance below 0.1% per surface
  • High laser damage threshold suitable for ultrafast femtosecond and picosecond lasers
  • λ/6 surface irregularity and 20-10 scratch-dig surface quality for excellent wavefront preservation
  • Low absorption and minimal scatter for high-power laser systems
  • Precision centration error below 3 arcminutes for accurate optical alignment

Applications

  • Beam focusing in ultrafast laser systems
  • Green laser processing at 515 nm
  • Precision micromachining and laser material processing
  • Scientific spectroscopy and laboratory optics
  • Semiconductor manufacturing and wafer processing
  • Biomedical laser instrumentation
  • Optical research and photonics development
  • High-power laser beam delivery and conditioning

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What type of lens is the PCX-F150-UVFS-25.4-ET2.0-AR784-AR784?
It is a precision plano-convex spherical lens manufactured from UV grade fused silica and optimized for high-performance laser applications at 515 nm.
Why is ion beam sputtered (IBS) coating beneficial?
IBS coatings provide exceptionally low reflectance, high environmental durability, low absorption, and excellent coating uniformity, making them ideal for demanding ultrafast laser systems.
Is this lens suitable for femtosecond lasers?
Yes. The lens is specifically designed for femtosecond and picosecond laser applications, offering low group delay dispersion, high transmission, and a high estimated laser-induced damage threshold for reliable ultrafast pulse handling.
What are the main advantages of UV fused silica?
UV fused silica provides excellent transmission from the ultraviolet through the near infrared, outstanding thermal stability, low autofluorescence, and high resistance to laser-induced damage, making it a preferred material for precision laser optics.
Which laser systems can use this lens?
The lens is well suited for 515 nm second-harmonic ultrafast laser platforms used in industrial and scientific environments, including systems for precision micromachining, semiconductor processing, biomedical research, and advanced photonics laboratories.

Got more questions? Use the inquiry form to ask the supplier directly.
