Description

The OPTOMAN PCV-F50-UVFS-25.4-CT2.0-AR548-AR548 is a high-precision UV fused silica plano-concave laser lens designed for advanced 1030 nm ultrafast laser applications. Featuring a -50 mm focal length, 25.4 mm diameter, and IBS anti-reflective coating with reflectance below 0.1% at 1030 nm, this concave lens provides reliable beam expansion and divergence control while minimizing optical losses.

Manufactured from UVFS (JGS1) material with excellent surface quality, low wavefront distortion, and high laser damage resistance, the PCV-F50 lens is optimized for femtosecond and picosecond laser systems where beam stability, efficiency, and precise optical control are essential. Its AR548 coating supports high transmission and reduced back reflections, making it suitable for demanding laser processing, scientific research, and nonlinear optics applications.

PCV-F50-UVFS-25.4-CT2.0-AR548-AR548 1030nm UVFS Plano-Concave Laser Lens

Specifications

Lens Type: Plano-Concave
Material: FS
Diameter: 25.4 mm
Focal Length: -50 mm
Edge Thickness, Te: 5.823 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCV-F50-UVFS-25.4-CT2.0-AR548-AR548
FindLight SKU: FL-24751

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • UV fused silica (UVFS/JGS1) substrate for excellent transmission, low thermal expansion, and high laser durability
  • Plano-concave optical design with -50 mm focal length for precise beam divergence control and expansion applications
  • 25.4 mm diameter format for compatibility with standard optical mounting systems
  • AR548 anti-reflective coating optimized for 1030 nm laser wavelengths to minimize reflection losses
  • High surface quality and low wavefront distortion for accurate beam shaping performance
  • Designed for ultrafast laser systems, including femtosecond and picosecond laser applications
  • Excellent thermal stability for demanding high-power laser environments
  • Suitable for precision photonics systems requiring reliable optical performance and low transmission losses

Applications

  • Beam expansion and beam conditioning systems for laser applications
  • 1030 nm Yb-based femtosecond and picosecond laser systems
  • Ultrafast laser material processing, including cutting, drilling, and micromachining
  • Nonlinear optics experiments and frequency conversion setups
  • Scientific research and laboratory photonics instruments
  • Laser alignment, beam shaping, and optical diagnostics systems
  • Industrial laser systems requiring precise divergence control and stable optical performance

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the OPTOMAN PCV-F50-UVFS-25.4-CT2.0-AR548-AR548 lens used for?
The OPTOMAN PCV-F50-UVFS-25.4-CT2.0-AR548-AR548 is used for laser beam divergence control, beam expansion, and optical conditioning in precision photonics systems.
What wavelength range is this plano-concave lens designed for?
This lens is optimized for 1030 nm laser applications and includes an AR548 anti-reflective coating designed to improve transmission performance at this wavelength.
Why is UV fused silica used for this laser lens?
UV fused silica provides excellent optical transmission, low thermal expansion, high laser damage resistance, and reliable performance in demanding laser environments.
Can this lens be integrated into ultrafast laser systems?
Yes, the lens is designed for ultrafast laser applications such as femtosecond and picosecond laser systems where precise beam control and low optical losses are required.
What makes the AR548 coating beneficial for laser applications?
The AR548 coating reduces reflection losses at the operating wavelength, increasing system efficiency and improving overall laser transmission performance.

Got more questions? Use the inquiry form to ask the supplier directly.
