Description

The OPTOMAN CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905 is a high-performance ultrafast convex optical lens designed for precision laser beam manipulation in femtosecond and picosecond laser systems. Manufactured from UV fused silica (UVFS/JGS1), this convex-convex lens features a 750 mm focal length and a 12.7 mm diameter format, providing reliable focusing performance with excellent optical clarity.

The lens incorporates OPTOMAN’s ion beam sputtered (IBS) anti-reflection coating technology optimized for the 1010–1050 nm wavelength range, delivering very low reflection losses and minimizing absorption effects during high-intensity laser operation. With high surface quality, low wavefront distortion, and excellent centration accuracy, this lens is engineered to maintain beam quality and reduce unwanted optical effects in advanced ultrafast photonics applications.

CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905 Ultrafast Convex Lens 750mm FL

Specifications

Lens Type: Bi-Convex
Material: UVFS
Diameter: 12.7 mm
Focal Length: 750 mm
Edge Thickness, Te: 3 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/8
Manufacturer Part Number (MPN): CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905
FindLight SKU: FL-24747

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Ultrafast laser optimized convex-convex lens for femtosecond and picosecond applications
  • Manufacturer part number: CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905
  • UV fused silica (JGS1) substrate for excellent transmission and thermal stability
  • 750 mm focal length at 546 nm with ±0.5% tolerance
  • 12.7 mm diameter design with 3.0 mm edge thickness
  • IBS anti-reflection coating with AR <0.1% from 1010–1050 nm and AR <0.05% at 1030 nm
  • High laser damage resistance and low absorption coating performance
  • Surface quality of 20-10 scratch-dig according to MIL-PRF-13830B standards
  • Surface irregularity better than λ/8 at 633 nm over clear aperture
  • Low centration error below 3 arcminutes for precision optical alignment

Applications

  • Femtosecond laser systems
  • Picosecond laser applications
  • Ultrafast amplifier and oscillator setups
  • Laser beam focusing and beam shaping systems
  • Nonlinear optics experiments
  • Precision spectroscopy and scientific research instruments
  • Industrial laser processing systems
  • Optical assemblies requiring low-loss NIR transmission

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the focal length of the OPTOMAN CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905 lens?
The lens has a 750 mm focal length measured at 546 nm, making it suitable for precise beam focusing and optical system integration where a long focal length is required.
What wavelength range is this ultrafast lens designed for?
This lens is optimized for operation from 1010 nm to 1050 nm, with peak anti-reflection performance around the 1030 nm wavelength commonly used in ultrafast laser systems.
What material is used for this OPTOMAN lens?
The lens is manufactured from UV fused silica (JGS1), a material known for excellent optical transmission, low thermal expansion, and strong performance in demanding laser environments.
Why is the IBS AR coating important for this lens?
The ion beam sputtered anti-reflection coating reduces reflection losses and absorption, helping improve laser efficiency while supporting high-intensity ultrafast laser applications.
Which laser systems can use the CXCX-F750-UVFS-12.7-ET3.0-AR905-AR905 lens?
This lens is suitable for ultrafast laser platforms including femtosecond and picosecond systems, as well as research and industrial optical setups requiring precise NIR beam control.

Got more questions? Use the inquiry form to ask the supplier directly.
