Description

The OPTOMAN CVCV-R86.59/R30.0-UVFS-20.0-CT3.0-AR548 is a high-precision ultrafast concave-concave lens designed for advanced laser beam expansion and divergence control applications. Manufactured from UV fused silica (UVFS) and featuring Ion Beam Sputtering (IBS) anti-reflective coatings, this optical element provides excellent transmission, minimal absorption, and reliable performance in high-intensity femtosecond and picosecond laser systems.

Optimized for 1030 nm operation, the lens features AR coatings with reflection below 0.1% at normal incidence, helping reduce optical losses while maintaining beam quality in demanding ultrafast laser environments. With precise radii of curvature, tight manufacturing tolerances, and a 20 mm diameter design, this lens is suitable for scientific, industrial, and research-grade photonics applications requiring accurate beam manipulation.

CVCV-R86.59/R30.0-UVFS-20.0-CT3.0-AR548 Ultrafast Concave Lens 1030 nm

Specifications

Lens Type: Bi-Concave
Material: UVFS
Diameter: 20 mm
Focal Length: -49.51 mm
Edge Thickness, Te: 3 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/4
Manufacturer Part Number (MPN): CVCV-R86.59/R30.0-UVFS-20.0-CT3.0-AR548-AR548
FindLight SKU: FL-24746

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Designed for ultrafast laser systems operating at 1030 nm wavelength
  • Concave-concave optical design for beam divergence adjustment and beam expansion
  • High-quality UV fused silica substrate for excellent UV-to-NIR transmission
  • IBS anti-reflective coating with reflectivity below 0.1% at 1030 nm
  • Low absorption and reduced thermal effects for high-power laser applications
  • Optimized for femtosecond and picosecond pulse systems with minimal dispersion impact
  • 20 mm diameter with 3 mm central thickness
  • High surface quality of 20-10 scratch-dig and precision optical fabrication
  • Low wavefront distortion with surface irregularity below λ/4 at 633 nm
  • Suitable for integration into advanced Yb-based ultrafast laser platforms

Applications

  • Femtosecond laser beam expansion systems
  • Picosecond laser optical assemblies
  • Yb:YAG ultrafast laser systems
  • Industrial laser processing equipment
  • Scientific research laser setups
  • Precision photonics experiments
  • Nonlinear optics and ultrafast spectroscopy
  • High-power laser beam conditioning and propagation systems
  • Optical systems requiring low-loss 1030 nm beam control

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the OPTOMAN CVCV-R86.59/R30.0-UVFS-20.0-CT3.0-AR548 lens designed for?
This lens is designed for ultrafast laser applications where precise beam divergence control and beam expansion are required. It is commonly used in femtosecond and picosecond laser systems operating around 1030 nm.
What wavelength is this OPTOMAN lens optimized for?
The lens is optimized for 1030 nm laser systems and features AR548 coatings designed to provide extremely low reflection losses at this wavelength.
What material is used for manufacturing this lens?
The lens is manufactured from UV fused silica (UVFS), a material known for excellent optical transmission, low thermal expansion, and strong performance in demanding laser environments.
What type of coating does the CVCV-R86.59/R30.0-UVFS-20.0-CT3.0-AR548 lens have?
It uses Ion Beam Sputtering (IBS) anti-reflective coatings on both surfaces, providing reflectivity below 0.1% at 1030 nm for improved transmission efficiency.
Which laser systems can use this ultrafast concave lens?
The lens is suitable for various Yb-based ultrafast laser platforms, including industrial and research laser systems requiring high-performance beam control and low optical losses.

Got more questions? Use the inquiry form to ask the supplier directly.
