Laser Glass - Er:Glass
Description
Erbium and ytterbium co-doped phosphate glass has a broad application because of the excellent properties. Mostly, it is the best glass material for 1.54μm laser due to its eye safe wavelength of 1540 nm and high transmission through atmosphere. It's also suitable for medical applications where the need for eye protection may be difficult to manage or diminish or hinder essential visual observation. Recently it is used in optical fiber communication instead of EDFA for its more super plus. There is a great progress in this field.
EAT14 is Erbium Glass doped with Er 3+ and Yb 3+ and suited to applications involving high repetition rates (1 - 6 Hz) and being pumped with 1535 nm laser diodes. This glass is available with high levels of Erbium (up to 1.7%).
Cr14 is Erbium Glass doped with Er 3+, Yb 3+ and Cr 3+ and suited to applications involving xenon lamp pumping. This glass is often used in laser range finder (LRF) applications.
Laser Glass - Er:Glass
Specifications |
|
|---|---|
| Type Of Crystal: | Ho:Cr:Tm:YAG, TeO2 |
| Crystal Diameter: | 2.5 mm |
| Crystal Length: | 2.5 mm |
| AR Coating: | Both sides |
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2018
Frequently Asked Questions
Er:Glass is erbium and ytterbium co-doped phosphate glass that has excellent properties and is suitable for a variety of applications, including 1.54μm laser, medical applications, and optical fiber communication.
The wavelength of Er:Glass is 1540 nm, which is eye safe and has high transmission through the atmosphere.
The variants of Er:Glass available are EAT14 and Cr14. EAT14 is Erbium Glass doped with Er3+ and Yb3+ and suited to applications involving high repetition rates (1-6Hz) and being pumped with 1535nm laser diodes. Cr14 is Erbium Glass doped with Er3+, Yb3+ and Cr3+ and suited to applications involving xenon lamp pumping.
The transformation temperature of EAT14 is 556ºC and the transformation temperature of Cr14 is 455ºC.
The chemical durability of EAT14 is 52 ug/hr.cm2 at 100ºC weigh loss rate distilled water, and the chemical durability of Cr14 is 103 ug/hr.cm2 at 100ºC weigh loss rate distilled water.
