Description
Er: YAG is a kind of excellent 2.94 um laser crystal, widely used in laser medical system and other fields. Er: YAG crystal laser is the most important material of 3nm laser, and the slope with high efficiency, can work at room temperature laser, laser wavelength is within the scope of the human eye safety band, etc. 2.94 mm Er: YAG laser has been widely used in medical field surgery, skin beauty, dental treatment.
Laser Crystal - Er:YAG
Specifications
| Type Of Crystal: | Ho:Cr:Tm:YAG |
|---|---|
| Crystal Diameter: | 7 mm |
| Crystal Length: | 100 mm |
| AR Coating: | Both sides |
Download Data Sheet
Frequently Asked Questions
What is Er:YAG laser crystal used for?
Er:YAG laser crystal is widely used in laser medical systems, skin beauty treatments, and dental procedures.
What are the advantages of Er:YAG crystals?
Er:YAG crystals have a high slope efficiency, operate well at room temperature, and emit light in a relatively eye-safe wavelength range.
What is the wavelength of the laser emitted by Er:YAG crystal?
The laser emitted by Er:YAG crystal has a wavelength of 2940nm.
What are the dimensions of Er:YAG laser crystal rods?
The diameter of Er:YAG laser crystal rods can range from 3-6mm and the length can range from 50-120mm upon request of the customer.
What is the thermal conductivity of Er:YAG crystal?
The thermal conductivity of Er:YAG crystal is 11.2Wm-1K-1.
