Description
The Carrier.L7550.XY，2D linear stage is a compact and high-performance piezoelectric motion unit designed for room temperature (RT) applications. It is part of the "Lab Series" by MultiFields Technologies and offers precise and reliable motion control.
The piezo-linear stage features a closed-loop control system and supports resistance type position sensing. With its ultra-quiet motion and 20 kHz drive frequency, it provides smooth and accurate movement. The Carrier.L7550.XY is available in different versions, including non-magnetic, high vacuum, and ultra-high vacuum options, catering to various application requirements.
Carrier.L7550.XY 2D Linear Stage with Piezoelectric Actuator
Specifications
| Axes Of Motion: | One |
|---|---|
| Travel Range: | 75 mm |
| Load Capacity (Horizontal): | 2 kg |
| Load Capacity (Vertical): | Not Specified |
| Max Speed: | 10 mm/s |
| Weight: | 2.4 kg |
| Guiding Mechanism: | Other |
| Voltage Requirement: | Other |
| Mini Step Size: | 10 nm |
| Full Range: | 0.8 mrad |
Download Data Sheet
Features
- XY Range: 75 mm × 50 mm
- Minimum step size: ~10 nm
- Maximum speed: 10 mm/s
- Close loop resolution:1 nm /2.44 nm /4.88 nm / 10 nm
- Trough hole (full range guaranteed): 85 mm × 65 mm
- Non-magnetic (.NM), High vacuum (.HV) and Ultra-high vacuum (.UHV) optional
- Material: Aluminum Alloy (main body)
Applications
- Work in a glove box
- Precision positioning
- Microscopy
- Optics and photonics research
- Semiconductor manufacturing
- Life science applications
- Metrology and inspection systems
