Page 2 - Photomultiplier Tubes (PMT)

Photomultiplier Tube (PMT) by ADIT Electron Tubes.The B29B03H is a 29mm (1-1/8\") diameter, 11-stage end- on photomultiplier designed for scintillation counting and other applications where high quantum efficiency, low dark current, good collection efficiency, and gain stability are of paramount importance.Short version of ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The B29B02H is a 29mm (1-1/8\") diameter, 11-stage end- on photomultiplier designed for scintillation counting and other applications where high quantum efficiency, low dark current, good collection efficiency, and gain stability are of paramount importance.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The B29B01W is a 29mm (1-1/8\") diameter, 11-stage end- on photomultiplier designed for scintillation counting and other applications where high quantum efficiency, low dark current, good collection efficiency, and gain stability are of paramount importance.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-630nm
Rise Time: 5 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9954B is a 51mm (2”) diameter end window photomultiplier, with enhanced green sensitive bialkali photocathode, and 12 BeCu dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 290-680nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9924QB is a 29 mm (1.13”) diameter, end window photomultiplier with enhanced UV sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of box and grid design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 200 nm
Wavelength Range: 160-680nm
Rise Time: 15 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9924B is a 29 mm (1.13”) diameter, end window photomultiplier with enhanced green sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of box and grid design. The 9924QB is a variant for applications requiring uv sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-680nm
Rise Time: 15 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9902B is a 38 mm (1.5”) diameter, end window photomultiplier with enhanced green sensitive bialkali photocathode and 10 high gain, high stability, SbCs dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 290-680nm
Rise Time: 3 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9893/350B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive photocathode, electrostatically reduced to 9mm diameter, and 14 BeCu dynodes of linear focused design for fast timing and extended linearity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9888B is a 29 mm (1.13”) diameter, end window photomultiplier with high temperature bialkali photocathode and 11 BeCu dynodes of box grid design. It is suitable for use with temperatures up to 150 degrees C

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 15 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9879B is a 51mm (2”) diameter end window photomultiplier, with S20 infra-red sensitive photocathode on a sandblasted window for enhanced cathode sensitivity, and 12 BeCu dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-870nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9878B is a 29 mm (1.13”) diameter, end window photomultiplier with high temperature bialkali photocathode and 11 BeCu dynodes of box grid design. It is suitable for use with temperatures up to 150 degrees C.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 15 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9863/350B is a 51mm (2”) diameter, end window photomultiplier with infra-red sensitive S20 photocathode, electrostatically reduced to 9mm diameter, and 14 BeCu dynodes of linear focused design for fast timing and extended linearity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-850nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9829B is a 51 mm (2”) diameter, end window photomultiplier with a thin domed window, sandblasted for enhanced cathode sensitivity, blue-green sensitive bialkali photocathode and 12 BeCu dynodes of linear focused design for good linearity and timing. The ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9828B is a 29 mm (1.13\") diameter, end window photomultiplier with prismatic window, S20 infra-red sensitive photocathode and 11 high gain, high stability SbCs dynodes of box and grid design. The 9828WB is a variant for applications requiring uv sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-870nm
Rise Time: 15 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9823B is a 130mm (5”) diameter end-window photomultiplier with blue-green sensitive bialkali photocathode on a plano-concave window. It has 14 BeCu dynodes of linear focused design for good linearity and timing. The 9823QB is a variant for applications ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2.7 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9822B is a 78mm (3”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode on a plano-concave window, and 10 BeCu dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 285-630nm
Rise Time: 2.1 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9821B is a 78mm (3”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode on a plano-concave window, and 12 BeCu dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 285-630nm
Rise Time: 2.1 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9817B is a 51mm (2”) diameter end window photomultiplier, with S20 infra-red sensitive photocathode, and 12 BeCu dynodes of linear focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-870nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9814B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 12 BeCu dynodes of linear focused design.The 9814QB is a variant for applications requiring UV sensitivity

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9813B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 14 BeCu dynodes of linear focused design. The 9813QB is a variant for applications requiring uv sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9807B is a 51 mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 12 high gain, high stability, BeCu dynodes of linear focused design for good linearity and timing. It is a plug-in replacement for the RCA 8575 and ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9781B is a 29 mm (1.13“) diameter, side window photomultiplier with a blue green sensitive bialkali photocathode and 9 high gain, high stability, SbCs dynodes of circular focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 300 nm
Wavelength Range: 165-680nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9780B is a 29 mm (1.13“) diameter, side window photomultiplier with a blue green sensitive bialkali photocathode and 9 high gain, high stability, SbCs dynodes of circular focused design. The 9780QB is a variant for applications requiring extended UV sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 300 nm
Wavelength Range: 165-680nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9424B is a 51 mm (2”) diameter end window photomultiplier with magnesium fluoride window, potassium bromide photocathode and 14 BeCu dynodes of linear focused design for extended linearity.It is supplied with spectral response data at specific wavelengths in ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 125 nm
Wavelength Range: 110-160nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9422B is a 51 mm (2”) diameter end window photomultiplier with magnesium fluoride window, caesium telluride photocathode and 14 BeCu dynodes of linear focused design for extended linearity.It is supplied with spectral response data at specific wavelengths in ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 225 nm
Wavelength Range: 110-360nm
Rise Time: 2 ns
Data Sheet
