Description

The next product in Advanced Optowave’s ultra short-pulsed laser product line is the AOFemto™ Series. Like the AOPico™ Series, the AOFemto™ is also a diode-pumped solid-state Hybrid master-oscillator power-amplifier, the main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.

Our complete ultra short pulsed laser product line is built on a common platform and we have designed it to use components that we also use in our nanosecond product line, components that have a solid track record for being highly reliable and stable. Because of the common components utilization, we can provide you, the customer, with a much more cost-effective products.

Ultrashort pulse lasers have the unique ability to machine materials with little or no thermal damage, and the ability to machine materials that have not previously been able to be process with lasers.

AOFemto 515nm 5W DPSS Laser

Specifications

Avg. Power: 5 W
Wavelength: 515 nm
Repetition Rate: 1 – 100 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.0008 ns
Pulse-to-Pulse Stability (RMS): 2 %
Cooling: Water-to-Water
Energy: 20 µJ
Repetition Rate: Single Shot to 1000 kHz
Beam Roundness: >85%
Beam Diameter: 2.0 mm
Beam Divergence: <1.3 mRad
Polarization Ratio: 100:1 Linear, Vertical
Polarization Ratio: 100:1 Linear, Horizontal
Pulse-to-Pulse Stability: <2% RMS
Operational Temperature Range: 15 to 30 ºC
Storage Temperature Range: -20 to 50 ºC
Input Voltage: 90 to 260 VAC

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Lowest Cost of Ownership: Designed to offer the most economical solution in the industry.
  • Excellent Beam Quality: Achieves an M2 value of less than 1.3 for superior performance.
  • Versatile Wavelength Options: Available in IR (1030 nm), Green (515 nm), and UV.
  • High Average Power: Delivers up to 15W of average power for demanding applications.
  • Ultra-Short Pulse Durations: Features pulse durations of less than 800 femtoseconds.
  • Reliable Design: Engineered for high reliability and consistent operation.
  • Burst Mode Option: Includes a burst mode for enhanced flexibility in various applications.



Applications

  • Injector Drilling
  • Medical Device Manufacturing
  • Polymer Processing/Machining
  • Semiconductor/PV Processing/Wafer Scribing
  • High-Precision, High-Speed Micro-machining
  • Brittle Material Cutting, Drilling, Dicing & Sub-Surface Marking

Frequently Asked Questions

What is the AOFemto™ Series laser used for?
The AOFemto™ Series laser is used for high-precision, high-speed micro-machining, brittle material cutting, drilling, dicing, and sub-surface marking. It is also used for injector drilling, medical device manufacturing, polymer processing/machining, and semiconductor/PV processing/wafer scribing.
What is the difference between the AOFemto™ and AOPico™ Series lasers?
The AOFemto™ and AOPico™ Series lasers are both diode-pumped solid-state Hybrid master-oscillator power-amplifiers, but the AOFemto™ has a compressor that enables it to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.
What is the average power of the AOFemto™ Series laser?
The AOFemto™ Series laser has an average power of up to 15 watts in the IR and 7.5 watts in the green.
What is the warranty for the AOFemto™ Series laser?
Advanced Optowave Corporation offers a limited warranty for the AOFemto™ Series laser.
What is the pulse duration of the AOFemto™ Series laser?
The pulse duration of the AOFemto™ Series laser is less than 800 femtoseconds.

Got more questions? Use the inquiry form to ask the supplier directly.
