JOLD-120-QPXF-2P W 940: Fiber Coupled Diode Laser
Description
The JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser is a high-performance laser system designed for a wide range of applications. With its passively cooled design using tap water, this laser offers efficient and reliable performance in various industries, including lasers and material processing, optical systems, industrial metrology, traffic solutions, defense, and civil systems.
Featuring a high optical output power of 120 W qcw (quasi-continuous wave), this laser module provides exceptional power for demanding tasks. The fiber core diameter of 600 μm (NA 0.22) ensures efficient light transmission and precise targeting, making it ideal for pumping solid-state lasers and fiber lasers, as well as material processing and medical applications.
The JOLD-120-QPXF-2P W comes with an integrated pilot laser and power monitor, allowing for easy alignment and monitoring of the laser's power output. This feature enhances usability and ensures consistent performance.
This diode laser boasts a long lifetime of over 1 GShot, indicating its high reliability and durability. It is designed to withstand demanding operational conditions and deliver consistent performance over an extended period.
The laser module operates in qcw mode and offers a maximum pulse length of ≤ 0.3 ms with a duty cycle of ≤ 20%. The center wavelength at 25 °C is 808 nm, with a variation of 5 nm.
JOLD-120-QPXF-2P W 940: Fiber Coupled Diode Laser
Specifications |
|
|---|---|
| Laser Type: | Continuous Wave (CW) |
| Fiber Type: | Multi-Mode |
| Wavelength: | 940 nm |
| Output Power: | 2000 mW |
| Fiber Core Diamater: | 120 um |
| Fiber Cladding Diameter: | 0 um |
Features
- High optical output power of 120 W qcw
- Fiber core diameter: 600 μm (NA 0.22)
- Integrated pilot laser and power monitor
- Long lifetime > 1GShot, high reliability
Applications
- Pumping of solid-state lasers and fiber lasers
- Material processing
- Medical applications
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2014
Frequently Asked Questions
The JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser boasts a long lifetime of over 1 GShot, indicating its high reliability and durability. It is designed to withstand demanding operational conditions and deliver consistent performance over an extended period.
The JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser is a high-performance laser system designed for a wide range of applications, including lasers and material processing, optical systems, industrial metrology, traffic solutions, defense, and civil systems.
Yes, the JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser comes with an integrated pilot laser and power monitor, allowing for easy alignment and monitoring of the laser's power output.
The JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser has a high optical output power of 120 W qcw (quasi-continuous wave), providing exceptional power for demanding tasks.
The fiber core diameter of the JOLD-120-QPXF-2P W Fiber-Coupled Diode Laser is 600 μm (NA 0.22), ensuring efficient light transmission and precise targeting.
