Description
Eblana Photonics presents the EP1550-0-NLW-100 kHz Series, a benchmark in the realm of monolithic, ultra-narrow linewidth laser diodes operating in the near-infrared spectrum. These laser diodes are meticulously engineered using Eblana's proprietary Discrete Mode technology platform, providing an unmatched solution for applications that demand supreme spectral purity, even under the most challenging environmental conditions. The EP1550-0-NLW-100 kHz series is distinguished by its remarkably narrow linewidths, achieving standard linewidths down to sub 100 kHz, which ensures exceptional performance and reliability.
The monolithic design of the EP1550-0-NLW-100 kHz eliminates the need for an external cavity, enhancing the robustness and stability of these laser diodes. This design allows for tunability through either temperature or current adjustments, providing flexibility and precision in various operational settings. Additionally, these diodes exhibit low sensitivity to mechanical vibrations, making them ideal for environments where stability is paramount. For those requiring more advanced configurations, injection locking versions are available, and wavelengths can be customized to meet specific requirements.
The EP1550-0-NLW-100 kHz series is packaged in a fiber-coupled 14-pin Butterfly with an optical isolator, ensuring seamless integration into existing systems. Key parameters of this series include a linewidth of less than 100 kHz, a side mode suppression ratio (SMSR) of 40 dB (typical), and a power output in fiber of 5 mW. The tuning range of 2 nm, coupled with optical isolation greater than 55 dB and a relative intensity noise (RIN) of 160 dB/Hz, underscores the precision and performance of these laser diodes.
For over a decade, Eblana Photonics has been at the forefront of delivering high-performance laser solutions. The company's expertise in Discrete Mode technology has enabled the development of innovative applications across various markets. With a commitment to quality and customer satisfaction, Eblana provides expert guidance and support for custom laser design, ensuring that each solution is tailored to meet the unique needs of its clients.
EP1550-0-NLW-100 kHz Series Ultra Narrow Linewidth Laser Diode
Specifications |
|
|---|---|
| Laser Type: | Modulated |
| Fiber Type: | Single Mode |
| Wavelength: | 1550 nm |
| Output Power: | 5 mW |
Features
- Industry Standard: Eblana's NLW series is the benchmark in monolithic, ultra-narrow linewidth laser diodes in the near infrared spectrum.
- Advanced Technology: Built on Eblana's Discrete Mode technology platform, delivering top spectral purity in challenging environments.
- Ultra-Narrow Linewidth: Standard linewidths are reduced to sub 100 kHz for precise applications.
- Monolithic Design: Features a monolithic design without the need for an external cavity.
- Tunable Options: Easily tunable via temperature or current adjustments.
- Vibration Resistant: Low sensitivity to mechanical vibration ensures stability.
- Customizable Wavelength: Wavelength can be specified to a custom value to meet specific needs.
- Injection Locking: Versions with injection locking are available for enhanced performance.
- Packaging: Delivered in a fiber-coupled 14-pin Butterfly package with optical isolator for optimal integration.
Applications
- Coherent Optical Communications: Enables stable, high-capacity data transmission.
- High-Resolution Optical Sensing: Delivers precise measurements in demanding environments.
- Spectroscopy & Metrology: Provides accurate, narrow-linewidth light sources.
- LIDAR & Remote Sensing: Enhances accuracy in ranging and detection systems.
- Atomic & Molecular Research: Supports experiments requiring ultra-stable lasers.
Frequently Asked Questions
The EP1550-0-NLW-100 kHz SERIES has standard linewidths down to sub 100 kHz, a monolithic design without external cavity, tunable by either temperature or current, low sensitivity to mechanical vibration, injection locking versions available, and wavelength may be specified to custom value.
The EP1550-0-NLW-100 kHz SERIES is a monolithic, ultra narrow linewidth laser diode in the near infrared that delivers precise narrow linewidth in a fiber coupled 14-pin Butterfly with optical isolator.
The optical isolation of the EP1550-0-NLW-100 kHz SERIES is greater than 55 dB.
The RIN of the EP1550-0-NLW-100 kHz SERIES is 160 dB/Hz.
The tuning range of the EP1550-0-NLW-100 kHz SERIES is 2 nm.
