Description
This is a 65W 878.5nm Fiber Coupled Diode Laser with VBG. The fiber-coupled laser diode uses 200μm, 0.22NA with an output power of 65W . It can be applied to pump fiber lasers, medical treatment, semiconductor lasers and fiber lasers, and material processing.
For tolerance wavelength locked, a reflective volume Bragg grating is used in order to solve the problem of semiconductor laser wavelength locking and narrow line width. It reduces the sensitivity of the grating to ambient temperature and vibration, and has achieved remarkable results in wavelength stabilization and line width compression of high-power semiconductor lasers.
Based on the angle and wavelength selectivity of the volume Bragg grating, the light waves emitted by each unit in the external cavity of the laser array are selected and fed back to the adjacent units to realize phase-locking of the external cavity of the laser array, and the spectral width is compressed to ten times of the original width.
First, the corresponding far-field divergence angle is below 1.5 mrad, which greatly improves the quality and stability of the beam output, so it is widely used.
65W 878.6nm Fiber Coupled Diode Laser
Specifications
| Laser Type: | Continuous Wave (CW) |
|---|---|
| Fiber Type: | Multi-Mode |
| Wavelength: | 878.6 nm |
| Output Power: | 65000 mW |
| Fiber Core Diamater: | 200 um |
| Fiber Cladding Diameter: | Not Specified |
| Fiber Core: | 200 um |
| Fiber Numerical Aperture: | 0.22 NA |
| Fiber Connector: | SMA905 |
| Operating Current Iop: | 9 A |
| Threshold Current Ith: | 1 A |
| Operating Voltage Vop: | 17 V |
| Power Conversion Efficiency: | 44 % |
| Operating Temp.: | 25~35 ℃ |
Download Data Sheet
Features
- 878.6nm central wavelength, 65W output power
- Fiber Bragg grating stabilization
- High power conversion efficiency
- High Reliability and stability
- Uniform intensity distribution
Applications
- Fiber Laser Pumping
- Material Processing
- Bio-medical instrument
- solid-state picosecond lasers
Frequently Asked Questions
What is the central wavelength of the 65W 878.6nm Fiber Coupled Diode Laser?
The central wavelength of the laser is 878.6nm.
What is the output power of the laser?
The laser has an output power of 65W.
What is the purpose of the Fiber Bragg grating in the laser?
The Fiber Bragg grating is used for wavelength stabilization and line width compression of high-power semiconductor lasers.
What are some applications of the laser?
The laser can be used for fiber laser pumping, material processing, bio-medical instruments, and solid-state picosecond lasers.
What is the power conversion efficiency of the laser?
The laser has a power conversion efficiency of 43%.
