Page 6 - Pulsed DPSS Lasers

This is a passively Q-switched 266nm solid-state semiconductor industrial laser source microchip MA series MA series microchip laser is a passively Q-switched solid-state laser based on semiconductor pump. The laser pulse is pure without tail, the single pulse energy is stable, and the beam quality is good. The integrated design of ...

Specifications

Avg. Power: 0.03 W
Wavelength: 266 nm
Repetition Rate: 1-20kHz
Spatial Mode (M^2): 1
Pulse Duration: 1.5 ns
...
Data Sheet
Our standard diode-pumped laser sources deliver up to 30 W at a wide range of repetition rates and pulse durations, both providing amazing results in biological tissue applications due to the excellent beam quality and the high level of water absorption. Less waste heat and a notably smaller cooling system, compared to flash-lamp ...

Specifications

Avg. Power: 5 W
Wavelength: 2810 nm
Repetition Rate: 0-0.5kHz
Spatial Mode (M^2): 10
Pulse Duration: < 100 ns
...
Data Sheet
The world\'s most powerful diode-pumped Tm:YAG laser module is available for industrial and medical applications. The average output power of up to 25 W and repetition rates of up to 500 Hz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 30 W
Wavelength: 2020 nm
Repetition Rate: 0-500kHz
Spatial Mode (M^2): <30
Pulse Duration: 100000 to 500000 ns
...
Data Sheet
The world\'s most powerful diode-pumped Tm:YAG laser module is available for industrial and medical applications. The average output power of up to 100 W and repetition rates of up to 500 Hz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 100 / 80 W
Wavelength: 2020 nm
Repetition Rate: 0-500kHz
Spatial Mode (M^2): 40
Pulse Duration: 100000 to 500000 ns
...
Data Sheet
The world\'s most powerful diode-pumped Er:YAG laser module is available for industrial and medical applications. The average output power of up to 2 W and repetition rates of up to 1 kHz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 2/1,2 W
Wavelength: 2940 nm
Repetition Rate: 0-1kHz
Spatial Mode (M^2): 5
Pulse Duration: 40000 to 1000000 ns
...
Data Sheet
The world\'s most powerful diode-pumped Tm:YAG laser module is available for industrial and medical applications. The average output power of up to 50 W and repetition rates of up to 500 Hz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 50 / 40 W
Wavelength: 2020 nm
Repetition Rate: 0-500kHz
Spatial Mode (M^2): 30
Pulse Duration: 100000 to 500000 ns
...
Data Sheet
The world\'s most powerful diode-pumped Er:YAG laser module is available for industrial and medical applications. The average output power of up to 25 W and repetition rates of up to 1 kHz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 25 / 16 W
Wavelength: 2940 nm
Repetition Rate: 0-1kHz
Spatial Mode (M^2): 25
Pulse Duration: 40000 to 1000000 ns
...
Data Sheet
The Merion MW is the flexible and high power version of the new diode-pumped nanosecond MERION series. The Merion MW is the most cost effective high performance diode-pumped Nd:YAG laser, which combines high energy and high repetition rate in the most compact package, utilizing state of the art, high efficiency laser diodes and gain ...

Specifications

Avg. Power: 30 W
Wavelength: 1064 nm
Repetition Rate: 0.1-0.2kHz
Spatial Mode (M^2): --
Pulse Duration: 5 - 9 ns
...
Data Sheet
The world\'s most powerful diode-pumped Er:YAG laser module is available for industrial and medical applications. The average output power of up to 50 W and repetition rates of up to 1 kHz allows controlled and at the same time precise treatments.

Specifications

Avg. Power: 50 / 33 W
Wavelength: 2940 nm
Repetition Rate: 0-1kHz
Spatial Mode (M^2): < 50
Pulse Duration: 40000 to 1000000 ns
...
Data Sheet
The Viron is a diode pumped Q-switched Nd:YAG laser. The Viron was specifically designed for high efficiency in a robust, compact package favored by instrumentation manufacturers. For more information

Specifications

Avg. Power: 0.6 W
Wavelength: 1064 nm
Repetition Rate: 0.02-0.02kHz
Spatial Mode (M^2): NA
Pulse Duration: 12 ns
...
Data Sheet
The Merion C is the newcomer in the Quantel laser diode-pumped nanosecond Nd:YAG range. This new DPSS laser combines all the advantages of the compact, powerful, reliable and cost-effective lasers you expect from Quantel laser. The Merion C delivers 100 mJ @ 1064 nm up to 400 Hz and can be equipped with fully integrated harmonic ...

Specifications

Avg. Power: 40 W
Wavelength: 1064 nm
Repetition Rate: 0.2-0.4kHz
Spatial Mode (M^2): NA
Pulse Duration: < 7 - 10 ns
...
Data Sheet
Owing to its intra-cavity patented technologies, the DMX YAG Green Series diode pumped laser has the simplest, most efficient design in a monolithic platform, while producing high power at 532 nm (up to 200W from single head and up to 400W from dual head) at kHz repetition rates. In addition to its simple, efficient design, the ...

Specifications

Avg. Power: 60-200 W
Wavelength: 532 nm
Repetition Rate: 1-50kHz
Spatial Mode (M^2): 15-20
Pulse Duration: 120 ns
...
Data Sheet
Owing to its patented technologies, the DMX Series Nd: YLF diode pumped laser has the simplest, most efficient design in a monolithic platform, while producing the highest pulse energy at 527 nm (100 mJ/pulse from single head and up to 200mJ from dual head) at kHz repetition rate. In addition to its simple, efficient high pulse ...

Specifications

Avg. Power: 30-150 W
Wavelength: 532 nm
Repetition Rate: 0.001-10kHz
Spatial Mode (M^2): 10-16
Pulse Duration: 100 ns
...
Data Sheet
With patented pulse selection and over a thousand picosecond lasers shipped worldwide, the RX Series lasers, with its new revolutionary packaging has smaller form factor and higher performance compared to its ancestor, the RGH series. The RX now provides from 10W to 100W of IR, 5W to 70W of Green and 3W to 45W of UV output powers on ...

Specifications

Avg. Power: 20-100 W
Wavelength: 355-1064 nm
Repetition Rate: 0.001-8000kHz
Spatial Mode (M^2): <1.2
Pulse Duration: 0.007 ns
...
Data Sheet
With patented pulse selection and over a thousand picosecond lasers shipped worldwide, the RX Series lasers, with its new revolutionary packaging has smaller form factor and higher performance compared to its ancestor, the RGH series. The RX now provides from 10W to 100W of IR, 5W to 70W of Green and 3W to 45W of UV output powers on ...

Specifications

Avg. Power: 3-30 W
Wavelength: 355-1064 nm
Repetition Rate: 0.001-8000kHz
Spatial Mode (M^2): <1.2
Pulse Duration: 0.007 ns
...
Data Sheet
The SN Series fills the gap for high power laser availability in the subnanosecond (i.e., ~50ps to 5ns) pulse width range. Such lasers have been identified as beneficial for a variety of micromachining and LIDAR applications, but until now, have been limited to only a few Watts of average power. Photonics Industries now offers a ...

Specifications

Avg. Power: 3-100 W
Wavelength: 355-1064 nm
Repetition Rate: 0.001-8000kHz
Spatial Mode (M^2): <1.3
Pulse Duration: 0.05-5 ns
...
Data Sheet
Our DX Series Long Pulse Nanosecond Lasers have smaller form factor, higher performance, and more flexibility in pulse width compared to its ancestor, the DSH series, providing the most compact UV output powers from 15W to 30W and Green output powers from 30W to 50W in a longer pulse configuration.  The DX Series Long Pulse ...

Specifications

Avg. Power: 16-50 W
Wavelength: 355-532 nm
Repetition Rate: 0.001-250kHz
Spatial Mode (M^2): <1.2
Pulse Duration: 65-340 ns
...
Data Sheet
Our DX Series Short Pulse Nanosecond Lasers have smaller form factor, higher performance and shorter pulse widths compared to its ancestor, the DSH series, providing the most compact UV output powers from 15W to 55W and Green output powers from 30W to 100W with short pulse width.

Specifications

Avg. Power: 15-100 W
Wavelength: 355-532 nm
Repetition Rate: 0.001-1000kHz
Spatial Mode (M^2): <1.1
Pulse Duration: 11 ns
...
Data Sheet
DIODE PUMPED ALL-SOLID-STATE PICOSECOND PULSED LASER Diode pumped all solid state picosecond pulsed laser at 213nm has the features of short pulse duration, high repetition rate and high average power, which is widely used in scientific research, fluorescence lifetime measurement and so on.    213nm UV Solid State Laser ...

Specifications

Avg. Power: 0.01 W
Wavelength: 213 nm
Repetition Rate: 5-6kHz
Spatial Mode (M^2): 1
Pulse Duration: 0.05 ns
...
Data Sheet
LD PUMPED ALL-SOLID-STATE LOW NOISE YELLOW LASER AT 594nm Low noise yellow laser at 594nm is made features of ultra compact, long lifetime, low cost and easy operating, which is widely used in collimation, laser medical treatment, scientific experiment, optical instrument, etc MLL-FN-594nm Orange Solid State Laser Wavelength (nm) ...

Specifications

Avg. Power: 100 W
Wavelength: 594 nm
Repetition Rate: 1-5kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 5 ns
...
Data Sheet
All Laserse solid state acousto-optic Q-switched laser at 266 nm has the features of high peak power, high repetition rate, and short pulse duration, which is widely used in material processing, measure, scientific research and so on.  More information about Actively laser. Wavelength (nm) 266+-1Operating mode ...

Specifications

Avg. Power: 0.01 W
Wavelength: 266 nm
Repetition Rate: 0.1-5kHz
Spatial Mode (M^2): 2
Pulse Duration: 4 ns
...
Data Sheet
1535nm Er Glass eye-safe laser—Ultra compact eye-safe laser for ranging finderLasers with emission wavelengths longer than 1.4 μm are often called “eye-safe”, because light in that wavelength range is strongly absorbed in the eye’s cornea and lens and therefore cannot reach the significantly more sensitive ...

Specifications

Avg. Power: 0.001 W
Wavelength: 1535 nm
Repetition Rate: 0.01-0.01kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 4.6 ns
...
Data Sheet
All solid state single longitudinal mode blue laser at 457nm is made features of ultracompact, long lifetime, low cost and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference,measurement, holography, physics experiment, etc.

Specifications

Avg. Power: 350 W
Wavelength: 457 nm
Repetition Rate: 0-0kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 0 ns
...
Data Sheet
Ready-Made Laser Systems RML-020-Nd:YAG PW 60
Electric System & Laser Technology
The Nd:YAG laser - based system operating in pulsed mode with the average power to 30 or to 60 [W]. The parameters regulated are: repetition frequency, pulse duration and peak power of a single pulse. The system is provided with an assembly enabling to obtain rectangular pulses, and with a microprocessor controller enabling to ...

Specifications

Avg. Power: 60 W
Wavelength: 1064 nm
Repetition Rate: 0.004-0.04kHz
Spatial Mode (M^2): --
Pulse Duration: 500000 ns
...
Data Sheet
Ready-Made Laser Systems RML-020-Nd:YAG PW 30
Electric System & Laser Technology
The Nd:YAG laser - based system operating in pulsed mode with the average power to 30 or to 60 [W]. The parameters regulated are: repetition frequency, pulse duration and peak power of a single pulse. The system is provided with an assembly enabling to obtain rectangular pulses, and with a microprocessor controller enabling to ...

Specifications

Avg. Power: 30 W
Wavelength: 1064 nm
Repetition Rate: 0.004-0.04kHz
Spatial Mode (M^2): --
Pulse Duration: 500000 ns
...
Data Sheet
