Description
High-Performance Air-Cooled SWIR camera, TEC2, Low Dark current, Long exposure applications, USB3.0 & CameraLink output, delivered with proprietary software and SDK: USB3.0 (WiDyVISION), CameraLink (WiDyCAM) and MicroManager adapter. Sensor noise: <40e-
Specifications
| Camera Type: | Scientific, Other, Military, Security, Industrial |
|---|---|
| Array Type: | InGaAs |
| Spectral Band: | 0.9 – 1.7 um |
| # Pixels (Height): | 512 |
| # Pixels (Width): | 640 |
| Pixel Pitch: | 15 um |
| Array Cooling: | Cooled |
| TEC: | TEC2 & air-cooled |
| Readout Noise: | <40e- |
| Frame Rate: | Up to 230Hz |
| Dark Current: | <1500 e-/pixels/s @-20°C |
| Exposure Time: | Up to 90s |
Download Data Sheet
Features
- TEC2 & fan aircooled
- Long exposure time
- High QE InGaAs from 900nm to 1700nm
- VGA resolution , 640x512 effective pixels
- Bad Pixels Replacement and Non Uniformity Correction
- USB3.0 & CameraLink interface
Applications
- Medical & Life Science
- Metrology (microscopy, hyperspectral)
- Process control (industry, semiconductors, food, etc.)
- Surveillance
- Photon counting
Frequently Asked Questions
What is the HiPe SenS camera used for?
The HiPe SenS camera is used for various applications including medical and life science, metrology, process control, surveillance, and photon counting.
What is the resolution of the HiPe SenS camera?
The HiPe SenS camera has a VGA resolution with 640x512 effective pixels.
What is the sensor noise level of the HiPe SenS camera?
The sensor noise level of the HiPe SenS camera is less than 40e-.
What type of interface does the HiPe SenS camera have?
The HiPe SenS camera has both USB3.0 and CameraLink interfaces.
Does the HiPe SenS camera come with any software or SDK?
Yes, the HiPe SenS camera is delivered with proprietary software and SDK, including USB3.0 (WiDyVISION), CameraLink (WiDyCAM), and MicroManager adapter.
