Page 3 - Wavelength-Division Multiplexing (WDM)

Wavelength Division Multiplexer 250 µm SM Fibers
Xenlux
Add to watch list
Wavelength Division Multiplexer 250 µm SM Fibers
Compare
These low-loss bidirectional fiber-optic wavelength division multiplexer (WDM) are based on graded-index (GRIN) lenses. Dichroic filters are used to combine or separate different wavelength. They exhibit low sensitivity to changes in modal distributions and are available in housings which can be mounted in standard splicing enclosures.

Specifications
Operating Wavelength: 1360 nm
Operating Bandwidth: -- nm
Isolation (min): 21 dB
Max Power Handling: -- W
Polarization Maintaining: No
Data Sheet
Wavelength Division Multiplexer 125 µm SM Fibers
Xenlux
Add to watch list
Wavelength Division Multiplexer 125 µm SM Fibers
Compare
These low-loss bidirectional fiber-optic wavelength division multiplexer (WDM) are based on graded-index (GRIN) lenses. Dichroic filters are used to combine or separate different wavelength. They exhibit low sensitivity to changes in modal distributions and are available in housings which can be mounted in standard splicing enclosures.

Specifications
Operating Wavelength: 1360 nm
Operating Bandwidth: -- nm
Isolation (min): 21 dB
Max Power Handling: -- W
Polarization Maintaining: No
Data Sheet
Wavelength Division Multiplexer 9 µm SM Fibers
Xenlux
Add to watch list
Wavelength Division Multiplexer 9 µm SM Fibers
Compare
These low-loss bidirectional fiber-optic wavelength division multiplexer (WDM) are based on graded-index (GRIN) lenses. Dichroic filters are used to combine or separate different wavelength. They exhibit low sensitivity to changes in modal distributions and are available in housings which can be mounted in standard splicing ...

Specifications
Operating Wavelength: 1360 nm
Operating Bandwidth: -- nm
Isolation (min): 21 dB
Max Power Handling: -- W
Polarization Maintaining: No
Data Sheet
3-Ports-1310, 1490, 1550nm Filter-Wavelength Division Multiplexer
Flyin Optronics Co Ltd
Add to watch list
3-Ports-1310, 1490, 1550nm Filter-Wavelength Division Multiplexer
Compare
Flyin Optronics\' Micro-Optical WDM utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provides low insertion loss, high channel isolation, low temperature sensitivity and epoxy free optical path.

Specifications
Operating Wavelength: 1310 nm
Operating Bandwidth: 100 nm
Isolation (min): 30 dB
Max Power Handling: 0.3 W
Polarization Maintaining: Yes, No
...
Data Sheet
Compact CWDM (CCWDM)
Flyin Optronics Co Ltd
Add to watch list
Compact CWDM (CCWDM)
Compare
Flyin’s compact size Coarse Wavelength Division Multiplexers(Mini CWDM, Compact CWDM, CCWDM), are integrated optical modules using Flyin’s proprietary optical bench platform which can significantly improve optical performance, while also reduce manufacturing cost. Compare to the common standard CWDM module, Flyin\'s Mini CWDM takes ...

Specifications
Operating Wavelength: 1270 nm
Operating Bandwidth: 13 nm
Isolation (min): 40 dB
Max Power Handling: 0.5 W
Polarization Maintaining: Yes, No
Data Sheet
100G 200G DWDM Module
Flyin Optronics Co Ltd
Add to watch list
100G 200G DWDM Module
Compare
Flyin Optronics’ 100GHz dense wavelength division multiplexer (DWDM) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging to achieve optical add and drop at the ITU wavelengths. It provides ITU channel center wavelength, low insertion loss, high channel isolation, wide pass ...

Specifications
Operating Wavelength: - nm
Operating Bandwidth: 0.3 nm
Isolation (min): 30 dB
Max Power Handling: 0.3 W
Polarization Maintaining: Yes, No
Data Sheet
1x2 CWDM
Flyin Optronics Co Ltd
Add to watch list
1x2 CWDM
Compare
Flyin Optronics’ Coarse wavelength division multiplexer (CWDM) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provides low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path.

Specifications
Operating Wavelength: 1270-1610 nm
Operating Bandwidth: 15 nm
Isolation (min): 13 dB
Max Power Handling: 0.3 W
Polarization Maintaining: Yes, No
Data Sheet
4, 8, 16 Channel CWDM Module
Flyin Optronics Co Ltd
Add to watch list
4, 8, 16 Channel CWDM Module
Compare
Flyin Optronics’ Coarse wavelength division multiplexer (CWDM Mux/Demux) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provides low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path.

Specifications
Operating Wavelength: 1270-1610 nm
Operating Bandwidth: 15 nm
Isolation (min): 30 dB
Max Power Handling: 0.3 W
Polarization Maintaining: Yes
...
Data Sheet
100 Gbps LAN-WDM TOSA LR4
Coset, Inc.
Add to watch list
100 Gbps LAN-WDM TOSA LR4
Compare
100 Gbps LAN-WDM TOSA LR4

Specifications
Operating Wavelength: 1300.05 nm
Operating Bandwidth: N/A nm
Isolation (min): N/A dB
Max Power Handling: 2 W
Polarization Maintaining: Yes, No
Data Sheet
100 Gbps LAN-WDM ROSA LR4
Coset, Inc.
Add to watch list
100 Gbps LAN-WDM ROSA LR4
Compare
100 Gbps LAN-WDM ROSA LR4

Specifications
Operating Wavelength: 1300.05 nm
Operating Bandwidth: N/A nm
Isolation (min): N/A dB
Max Power Handling: N/A W
Polarization Maintaining: Yes, No
Data Sheet
100 Gbps LAN-WDM ROSA ER4 Lite
Coset, Inc.
Add to watch list
100 Gbps LAN-WDM ROSA ER4 Lite
Compare
100 GbpsLAN-WDM ROSA ER4 Lite

Specifications
Operating Wavelength: 1300.05 nm
Operating Bandwidth: N/A nm
Isolation (min): N/A dB
Max Power Handling: N/A W
Polarization Maintaining: Yes, No
Data Sheet
PM Dense Wavelength Division Multiplexer（PMDWDM）100G
Shenzhen optics forest Co.,LTD
Add to watch list
PM Dense Wavelength Division Multiplexer（PMDWDM）100G
Compare
The multi-channel Dense Wavelength Division Multiplexer Modules are based on thin film PMDWDM  devices by cascading individual channels into sequence. Channel numbers can be as high as 40 (16) for 100 (200) GHz systems in C band or in L band. They are featured with wide passband,low insertion loss, high channel isolation and ...

Specifications
Operating Wavelength: 1550.12 nm
Operating Bandwidth: 0.4 nm
Isolation (min): 25 dB
Max Power Handling: 0.3 W
Polarization Maintaining: Yes
Data Sheet
1550/CWDM MUX/DEMUX Plug-in Module
Finisar Corporation
Add to watch list
1550/CWDM MUX/DEMUX Plug-in Module
Compare
1550/CWDM plug-in module is a passive optical multiplexer /demultiplexer designed to add CWDM wavelengths to an existing 1550nm backbone ring. The module multiplexes and demultiplexes a single 1550nm wavelength and five additional CWDM wavelengths in a two-fiber ring network. This MUX/DEMUX module plugs into one half of a 1RU, 19\" ...

Specifications
Operating Wavelength: 1471 nm
Operating Bandwidth: -- nm
Isolation (min): 30 dB
Max Power Handling: N/A W
Polarization Maintaining: No
...
Data Sheet
1310/CWDM MUX/DEMUX Plug-in Module
Finisar Corporation
Add to watch list
1310/CWDM MUX/DEMUX Plug-in Module
Compare
1310/CWDM plug-in module is a passive optical multiplexer/demultiplexer designed to add CWDM wavelengths to an existing 1310nm backbone ring. The module multiplexes and demultiplexes a single 1310nm wavelength and the complete CWDM wavelength grid from a two-fiber ring network. This MUX/DEMUX module plugs into one half of a 1RU, 19\" ...

Specifications
Operating Wavelength: 1464.5 nm
Operating Bandwidth: 1310 nm
Isolation (min): 45 dB
Max Power Handling: N/A W
Polarization Maintaining: No
...
Data Sheet
PM FWDM
Anylink Technology
Add to watch list
PM FWDM
Compare
The PM Filter WDM is characterized with low insertion loss, Wide Pass Band, high return loss, excellent environmental stability and reliability.

Specifications
Operating Wavelength: 1520 nm
Operating Bandwidth: 60 nm
Isolation (min): 0.7 dB
Max Power Handling: 0.5 W
Polarization Maintaining: Yes
Data Sheet
