Gradient Index Multimode Optical Fiber for VIS-IR Applications

Description

Welcome to the world of precision and innovation with The Quality Connection FiberTech, your trusted partner in laser beam transmission solutions. At the forefront of optical fiber technology, LEONI Fiber Optics excels in providing cutting-edge solutions for communication, industrial applications, sensor technology, analytics, science, and laser technology. Renowned for our comprehensive product range, we deliver excellence at every stage of the value chain, from the preform to the fibers, and onto complete fiber optic systems.

Advantages of Gradient Index Multimode Optical Fibers
Gradient index (GI) multimode optical fibers are designed with a refractive index profile that gradually decreases from the fiber core center toward the cladding. This structure helps reduce modal dispersion by allowing different propagation modes to travel at more similar effective velocities, resulting in improved bandwidth performance and signal integrity compared to conventional step-index multimode fibers. FiberTech Ultrasol GI multimode fibers are optimized for VIS-IR optical transmission applications requiring efficient light coupling, stable signal propagation, and reliable performance across industrial communication, sensing, spectroscopy, and photonics systems.

High-Bandwidth VIS-IR Transmission Performance
FiberTech Ultrasol gradient index multimode fibers are engineered to support high-bandwidth optical transmission at both 850 nm and 1300 nm wavelengths. The optimized refractive index profile minimizes modal dispersion, enabling improved signal integrity and enhanced data transmission performance in industrial communication, sensing, and photonics applications. Multiple core diameter options are available to support efficient optical coupling and system integration across a wide range of VIS-IR optical platforms.

Multiple Core Diameter Options for System Integration
FiberTech Ultrasol multimode fibers are available in a wide range of core diameters from 50 µm to 600 µm, enabling optimized optical coupling for communication systems, spectroscopy instruments, sensing platforms, and laser delivery applications. Larger core diameters provide improved alignment tolerance and higher optical throughput, while smaller cores support higher bandwidth transmission performance in data communication and photonics systems.

Specifications

Core Diameter:	50 um
Wavelength Range:	850 – 1300 nm
Cable Length:	Not Specified
Fiber Core Material:	Silica
Fiber Length:	Custom
Numerical Aperture:	0.2
Attenuation At 850 Nm:	3-2.7 dB/km
Attenuation At 1300 Nm:	1-0.7 dB/km
Bandwidth At 850 Nm:	300-600 MHz x km
Bandwidth At 1300 Nm:	600-1200 MHz x km
Coating Diameter:	250 um
Jacket Diameter:	125 um

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

LOSCH High-Power Technology: LEONI laser cables are designed with LOSCH High-Power Technology, making them ideal for transferring laser beam energy from industrial and medical laser systems.
Durability and Power Handling: These fiber cables can handle high power levels, ranging from several Watts to several Kilowatts, surpassing standard datacom and telecom fibers.
Wide Wavelength Compatibility: Suitable for fiber-coupled laser systems emitting in the UV to IR wavelength range, including high-power semiconductor lasers, solid-state lasers, and fiber lasers.
SMA and FC Interface Options: Available with F-SMA/SMA905 connectors, these cables feature free-standing fiber tips. CuSMA cables, with copper alloy ferrules, offer excellent heat removal and fiber alignment.
High Power Transmission: Achieve maximum laser power transmission with SMA500 and CuFC cables, which provide superior heat transfer capabilities.
LD-80 Interface Compatibility: The LD-80 interface is compatible with the Ø 4x10 mm Industrial Industry Standard, offering plug-and-play connections with high power transmission and laser safety features.
Laser Safety Features: Ensure safety with steel-armored protection tubes and optional electrical fiber break-detect systems in some products.
ModeStrip Technology: Advanced fiber cladding mode technology enhances the performance and reliability of laser beam transmission.

Applications

Industrial Optical Communication: High-bandwidth multimode transmission for industrial networking and automation systems.
VIS-IR Spectroscopy: Optical signal transmission for spectroscopy and analytical instrumentation operating in visible and infrared spectral regions.
Fiber Optic Sensing: Integration into industrial and scientific sensing systems requiring stable multimode optical transmission.
Laser Energy Delivery: Delivery of visible and infrared laser energy in industrial photonics and laboratory systems.
Biomedical Instrumentation: Optical transmission for medical diagnostics, imaging, and biomedical photonics applications.
Machine Vision Systems: Fiber coupling and signal transmission for industrial imaging and machine vision equipment.
Optical Metrology: Signal routing and light delivery in precision optical measurement and metrology systems.
Research and Photonics Development: Suitable for experimental photonics setups and VIS-IR optical characterization systems.
Data Communication Systems: High-bandwidth multimode transmission for short-range optical communication applications.
Sensor Networks: Optical connectivity for distributed sensing and monitoring systems in industrial environments.

Name

Work Email

Organization (recommended)

Your message to supplier

Ships from:: United States
Sold by:: Weinert Fiber Optics ✓ Verified Supplier
On FindLight:: since 2015

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What kind of connectors do LEONI laser cables have?

LEONI offers a variety of different laser cables with F-SMA/SMA905 connectors, depending on the beam power levels. All SMA connectors have a free-standing fiber tip. CuSMA cables with their distinctive copper alloy ferrule and excellent fiber alignment provide good heat removal and fiber centration. The CuFC connectors provide a connector interface for FC-style applications.

What is the advantage of using graded-index fibers for laser beam transmission?

The light rays within graded-index fibers will not follow a zigzag-path as in the case of a step-index profile. The fiber acts as a lens duct with the advantage that the input NA and the beam diameter at the fiber input will be preserved.

What kind of laser systems are LEONI laser cables suitable for?

LEONI laser cables are specially designed for transferring laser beam energy generated by industrial and medical laser systems, including high-power semiconductor lasers, solid-state lasers, and fiber lasers.

What is the difference between graded-index fibers and step-index fibers?

Due to the doping of the fiber core graded-index fibers have a lower laser damage threshold and a higher numerical aperture in comparison with step-index fibers.

What is the Business Unit Fiber Optics?

The Business Unit Fiber Optics is a leading producer of high-quality multimode fibers with graded index profile used for data transmission.

What is a gradient index multimode fiber?

A gradient index multimode fiber uses a gradually changing refractive index profile to reduce modal dispersion and improve bandwidth performance compared to step-index multimode fibers.

What are VIS-IR optical fibers used for?

VIS-IR optical fibers are used for optical communication, spectroscopy, sensing, laser delivery, machine vision, and photonics applications operating in visible and infrared wavelength ranges.

Why are multimode fibers used in industrial systems?

Multimode fibers provide high optical throughput, efficient coupling, and improved alignment tolerance, making them suitable for industrial communication and sensing applications.

What wavelengths are commonly used with multimode communication fibers?

Common multimode transmission wavelengths include 850 nm and 1300 nm due to their low attenuation and strong bandwidth performance.

What is the advantage of larger core multimode fibers?

Larger core fibers improve light collection efficiency, alignment tolerance, and optical power handling for sensing, spectroscopy, and laser delivery systems.
