Description
The ultra-stable polarization-maintaining single-mode fiber patch cable developed by CSRayzer is specially designed. Compared with the conventional polarization-maintaining fiber patch cable, it has the characteristics of ultra-high extinction ratio, low loss and high power, which ensures that the polarization direction of polarization state will not change when transmitting polarized light signals.
Each polarization-maintaining patch cable is tested separately at the alignment wavelength to ensure the polarization extinction ratio and loss at the optical fiber connection, which is widely used in optical path systems with extremely high polarization state requirements, such as quantum calculation and quantum precision measurement systems.
CSRayzer provides a variety of customization services for polarization-maintaining single-mode patch cable, such as any wavelength between 350-2000nm and any length.
Ultra-Stable PM Fiber Patch Cable for Quantum Optics/ Cold Atoms
Specifications |
|
|---|---|
| Wavelength Range: | 350-2000 nm |
| Optical Fiber Type: | PM Fiber |
| Typical Insertion Loss: | 1/0.8/0.5 dB |
| Polarization Extinction Ratio (ultra-stable): | 25 dB |
| Peak Power: | 100mW/300mW/2W/5W optional |
| Connector: | FC/APC or FC/PC is optional. |
Features
- The cutoff wavelength can be selected from 350-2000nm.
- Low loss
- High extinction ratio output
- High withstand power optional
Applications
- Quantum computing
- Cold Atom
- Quantum precision measurement
- Quantum communication
Frequently Asked Questions
The Ultra-stable PM Fiber Patch Cable is a polarization-maintaining single-mode fiber patch cable developed by CSRayzer, designed for ultra-high extinction ratio, low loss, and high power to ensure stable polarization direction during transmission of polarized light signals.
The key features include a selectable cutoff wavelength from 350-2000 nm, low loss, high extinction ratio output, and high withstand power options.
The cable is suitable for applications in quantum computing, cold atom systems, quantum precision measurement, and quantum communication.
CSRayzer offers customization services for any wavelength between 350-2000 nm and any cable length.
The available connector options are FC/APC or FC/PC.
The typical insertion loss ranges from 0.5 dB to 1 dB, depending on the wavelength range.
The polarization extinction ratio for the ultra-stable version is 23 to 25 dB, depending on the wavelength range.
