iHR550 Spectrometer
Description
The difference between iHR spectrometers and other standard Czerny-Turner spectrometers can be seen at first glance. The iHR series is not just another square box in your lab. The final design, with the unique shape of the iHR series, was adopted to provide the best solution for essential parameters in imaging spectrometers: image quality, removal of re-diffracted light and maximized optical throughput.
As an imaging spectrometer, the iHR has enhanced capabilities for use with a CCD. A toroidal mirror corrects for astigmatism, allowing the
tangential (resolution optimized) and sagittal (imaging optimized) focal planes to cross at the center of the focal plane. This provides the flexibility to choose between imaging and resolution optimization (with a CCD detector) by selecting the desired detection angle. The iHR Series
has one of the largest flat fields available in an imaging spectrograph. The imaging quality over the entire flat field has been maximized by using an asymmetric layout and a patented on-axis grating drive, reducing coma and other aberrations. A larger focus mirror allows the entire flat field to be used without vignetting (no throughput reduction at the edges of the focal plane).
iHR550 Spectrometer
Specifications |
|
|---|---|
| Monochromator Type: | Czerny-Turner |
| Effective Focal Length: | 550 mm |
| Diffraction Grating: | 1200 lines/mm |
| Grating Blaze Wavelength: | 435 nm |
| Spectral Range: | 150-1500nm |
| Linear Dispersion (Avg): | 1.34 nm/mm |
| Spectral Resolution (Avg): | 0.025 nm |
Features
The iHR provides a platform for spectroscopic measurements for years to come. The design of the spectrometer itself and its accompanying accessories and software enables users to customize the iHR for any experiment. This customization starts with the choice of entrance and exit ports, the library of HORIBA Scientific gratings, and the full line of spectroscopic accessories for various measurements.
SynerJY®, our general purpose spectroscopy software provides a platform for most measurements. Additional software possibilities are available, including our Software Development Kit and LabVIEW® VIs
Applications
Spectrometry
Spectroscopy
Industrial and Scientific applications
Imaging
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
Yes, the iHR provides a platform for spectroscopic measurements for years to come, with the ability to customize entrance and exit ports, gratings, and spectroscopic accessories, and software options including SynerJY®, a general purpose spectroscopy software, and a Software Development Kit and LabVIEW® VIs.
The iHR Series has one of the largest flat fields available in an imaging spectrograph, with imaging quality maximized over the entire flat field using an asymmetric layout and a patented on-axis grating drive.
The iHR spectrometer has enhanced imaging capabilities for use with a CCD, with a toroidal mirror that corrects for astigmatism and allows for resolution or imaging optimization.
The iHR spectrometer is suitable for a range of applications including spectrometry, spectroscopy, industrial and scientific applications, and imaging.
The iHR series has a unique design that provides better image quality, removal of re-diffracted light, and maximized optical throughput.
