Nonlinear crystals--KTiOPO4(KTP)

Name: Nonlinear crystals--KTiOPO4(KTP)
Brand: DIEN TECH
Availability: InStock

Description

Potassium Titanyl Phosphate (KTiOPO4 or KTP) is widely used in both commercial and military lasers including laboratory and medical systems, range-finders, lidar, optical communication and industrial systems.

Specifications

Crystal Type:	KTP (KTiOPO4)
Phase Mathcing Type:	Not Applicable
Mounting:	Unmounted
Width:	5 mm
Height:	5 mm
Length:	5 mm
Flatness:	<= Lambda/4
Surface Quality (Scratch-Dig):	20-10
AR Coating:	Both Sides

Download Data Sheet

Features

• Large nonlinear optical coefficient;

• Wide angular bandwidth and small walk-off angle;

• Broad temperature and spectral bandwidth;

• High electro-optic coefficient and low dielectric constant;

• Large figure of merit;

• Nonhydroscopic, chemically and mechanically stable.

Applications

• Frequency Doubling (SHG) of Nd-doped Lasers for Green/Red Output

• Frequency Mixing (SFM) of Nd Laser and Diode Laser for Blue Output

• Parametric Sources (OPG, OPA and OPO) for 0.6mm-4.5mm Tunable Output

• Electrical Optical(E-O) Modulators, Optical Switches, and Directional Couplers

• Optical Waveguides for Integrated NLO and E-O Devices

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is Potassium Titanyl Phosphate (KTP)?

Potassium Titanyl Phosphate (KTP) is a nonlinear crystal that is widely used in commercial and military lasers, including laboratory and medical systems, range-finders, lidar, optical communication, and industrial systems.

What are the features of KTP crystals?

KTP crystals have a large nonlinear optical coefficient, wide angular bandwidth, small walk-off angle, broad temperature and spectral bandwidth, high electro-optic coefficient, low dielectric constant, large figure of merit, and are nonhydroscopic, chemically and mechanically stable.

What are the applications of KTP crystals?

KTP crystals are used for frequency doubling (SHG) of Nd-doped lasers for green/red output, frequency mixing (SFM) of Nd laser and diode laser for blue output, parametric sources (OPG, OPA, and OPO) for 0.6mm-4.5mm tunable output, electrical optical (E-O) modulators, optical switches, and directional couplers, and optical waveguides for integrated NLO and E-O devices.

What are the basic properties of KTP crystals?

KTP crystals have an orthorhombic crystal structure, a melting point of 1172°C, a Curie point of 936°C, lattice parameters of a=6.404Å, b=10.615Å, c=12.814Å, and Z=8, and a density of 2.945g/cm3.

What are the technical parameters of KTP crystals?

KTP crystals have a dimension of 1x1x0.05-30x30x40mm, a phasematching type of Type II, θ=90°; φ=phase-matching angle, and typical coating of S1&S2: AR@1064nm R<0.1%; AR@532nm, R<0.25%. Customized coating is available upon customer request.
