Nonlinear crystals--BBO

Name: Nonlinear crystals--BBO
Brand: DIEN TECH
Availability: InStock

Description

BBO is a new ultraviole frequency doubling crystal.

Specifications

Crystal Type:	BBO (Beta Barium Borate)
Phase Mathcing Type:	Not Applicable
Mounting:	Unmounted
Width:	5 mm
Height:	5 mm
Length:	5 mm
Flatness:	<= Lambda/4
Surface Quality (Scratch-Dig):	20-10
AR Coating:	Both Sides

Download Data Sheet

Features

• Broad phase matchable range from 409.6 nm to 3500 nm;
  • Wide transmission region from 190 nm to 3500 nm;
  • Large effective second-harmonic-generation (SHG) coefficient about 6 times greater than that of KDP  crystal;
  • High damage threshold;
  • High optical homogeneity with δn ≈10-6/cm;
  • Wide temperature-bandwidth of about 55℃.

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is BBO?

BBO is a new ultraviolet frequency doubling crystal used in laser instruments.

What is the phase matchable range of BBO?

BBO has a broad phase matchable range from 409.6 nm to 3500 nm.

What is the effective second-harmonic-generation coefficient of BBO?

BBO has a large effective second-harmonic-generation (SHG) coefficient about 6 times greater than that of KDP crystal.

What is the damage threshold of BBO?

BBO has a high damage threshold of >1 for 1064nm, TEM00, 10ns, 10HZ (polished only), >0.5 for 1064nm, TEM00, 10ns, 10HZ (AR-coated), and >0.3 for 532nm, TEM00, 10ns, 10HZ (AR-coated).

What is the temperature-bandwidth of BBO?

BBO has a wide temperature-bandwidth of about 55℃.
