Name: Infrared Nonlinear Crystal - AgGaSe2 (AGSe2)
Brand: DIEN TECH
Availability: InStock

Description

AGSe2 AgGaSe2(AgGa(1－x)InxSe2) crystals have band edges at 0.73 and 18 µm. Its useful transmission range (0.9–16 µm) and wide phase matching capability provide excellent potential for OPO applications when pumped by a variety of different lasers. Tuning within 2.5–12 µm has been obtained when pumping by Ho:YLF laser at 2.05 µm; as well as non-critical phase matching (NCPM) operation within 1.9–5.5 µm when pumping at 1.4–1.55 µm. AgGaSe2 (AgGaSe) has been demonstrated to be an efficient frequency doubling crystal for infrared CO2 lasers radiation.

Specifications

Crystal Type:	AgGaSe2 (Silver Gallium Selenide)
Phase Mathcing Type:	Not Applicable
Mounting:	Mounted
Width:	8 mm
Height:	8 mm
Length:	20 mm
Flatness:	<= Lambda/4
Surface Quality (Scratch-Dig):	20-10
AR Coating:	Not Coated

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Applications

  • Generation second harmonics on CO and CO2 - lasers
  • Optical parametric oscillator
  • Different frequency generator to middle infrared regions up to 18um.
  • Frequency mixing in the middle IR region

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What is AGSe2?

AGSe2 is an infrared nonlinear crystal with band edges at 0.73 and 18 µm. It has a useful transmission range of 0.9–16 µm and wide phase matching capability.

What are the applications of AGSe2?

AGSe2 can be used for generating second harmonics on CO and CO2 lasers, optical parametric oscillators, different frequency generators to middle infrared regions up to 18um, and frequency mixing in the middle IR region.

What are the dimensions of AGSe2?

The standard cross sections of AGSe2 are 8x8mm and 5x5mm, and the crystal length ranges from 1 to 30mm. Custom sizes are also available on request.

What are the linear optical properties of AGSe2?

The transparency range of AGSe2 is 0.73-18.0um, and the refractive indices are no 2.7010, 2.6134, and 2.5912 @1.064um, 5.300um, and 10.60um, respectively.

What are the nonlinear optical properties of AGSe2?

The NLO coefficients of AGSe2 @10.6um are d36=d24=d15=39.5pm/V, and the linear electro-optic coefficients are Y41T=4.5pm/V and Y63T=3.9pm/V. The damage threshold @~10ns, 1.064um is 20-30MW/cm2 (surface).
