Magneto-Optical Crystal - TGG - Get a price quote from DIEN TECH

Name: Magneto-Optical Crystal - TGG
Brand: DIEN TECH
Availability: InStock

Description

TGG is an excellent magneto-optical crystal used in various Faraday devices (Rotator and Isolator) in the range of 400nm-1100nm, excluding 475-500nm.

Optical isolator devices make use of the non-reciprocal Faraday effect in TGG. The Faraday effect is the rotation of the plane of polarization of a light beam as it is transmitted through a material in the presence of an external magnetic field coaxial with the light. The polarization rotation is in the same sense regardless of the direction of propagation of the light. An optical isolator is a Faraday rotator combined with suitably aligned polarizers which allows light to pass in one direction only.

Specifications

Type Of Crystal:	TGG
Crystal Diameter:	2.8 mm
Crystal Length:	100 mm
AR Coating:	Both sides

Download Data Sheet

Features

Advantages:

• Large Verdet constant (35 Rad T-1m-1).

• Low optical losses (<0.1%/cm)

• High thermal conductivity (7.4W m-1K-1).

• High laser damage threshold (>1GW/cm2).

Applications

Rotator and Isolator

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is TGG?

TGG is an excellent magneto-optical crystal used in various Faraday devices (Rotator and Isolator) in the range of 400nm-1100nm, excluding 475-500nm.

What is the Faraday effect?

The Faraday effect is the rotation of the plane of polarization of a light beam as it is transmitted through a material in the presence of an external magnetic field coaxial with the light.

What are the advantages of TGG?

TGG has a large Verdet constant (35 Rad T-1m-1), low optical losses (<0.1%/cm), high thermal conductivity (7.4W m-1K-1), and high laser damage threshold (>1GW/cm2).

What are the applications of TGG?

TGG is used in Rotator and Isolator devices.

What are the technical parameters of TGG?

The technical parameters of TGG include orientation [111] within ±15 arcmin, wavefront distortion <1/8 wave, extinction ratio >35dB, diameter tolerance +0.00mm/-0.05mm, length tolerance +0.2mm/-0.2mm, chamfer 0.10mm@45º, flatness <1/10 wave at 633nm, parallelism <30 arcSeconds, perpendicularity <5 arcmin, surface quality 10/5 Scratch/Dig, and AR coating <0.2%.
