Description
Nd: YVO4 crystal is an excellent laser crystal for making diode pumped solid lasers. The main and greatest advantages of Nd: YVO4 are high absorption coefficient, big stimulated emission cross-section and wide absorption band, the absorption peak is about 808 nm.
Because of these advantages, small crystal can be used to make smaller laser device. Another feature of Nd: YVO4 crystal is the uniaxial, which makes it emit linearly polarized lights. Combining with frequency-doubled crystal, all-solid-state lasers with near-infrared, green, blue and ultraviolet wavelength can be realized.
Nd^3+:YVO4 crystal laser rods/slabs/wafers
Specifications
| Type Of Crystal: | Nd:YVO4 |
|---|---|
| Crystal Diameter: | 1 mm |
| Crystal Length: | 0.3 mm |
| AR Coating: | Both sides |
| Chemical Formula, Crystal: Activator: | YVO4: Nd3+ |
| Activator Concentration: | Nd3+: 0.1～3.0 at % |
| Optical Axial Angle: | +/-0.5° |
| Wavefront Distortion: | λ/8 per inch @ 632.8 nm |
| Dimensions: | as required |
| Tolerance: | Diameter：±0.02mm, Length: ±0.2mm |
| Surface Quality: | 10-5 (MIL-PRF-13830B) |
| Coating: | AR, HR as required |
| Parallelism: | ≤10″ |
| Perpendicularity: | ≤5′ |
| Surface Flatness: | λ/10 per inch @632.8nm |
| Clear Aperture: | >95% |
| Damage Threshold: | >750 MW/cm2 |
Download Data Sheet
Features
- High absorption coefficient
- Large stimulated emission cross section
- Wide absorption band
- High damage threshold
- Uniaxial crystal
Applications
- Diode pumped solid lasers
- Seed laser source
Frequently Asked Questions
What are the advantages of Nd: YVO4 crystal for making diode pumped solid lasers?
The main advantages of Nd: YVO4 crystal are its high absorption coefficient, big stimulated emission cross-section, and wide absorption band.
Can smaller laser devices be made using Nd: YVO4 crystal?
Yes, because of its high absorption coefficient and other advantages, smaller laser devices can be made using Nd: YVO4 crystal.
What is the emission characteristic of Nd: YVO4 crystal?
Nd: YVO4 crystal emits linearly polarized lights due to its uniaxial nature.
What types of lasers can be realized by combining Nd: YVO4 crystal with a frequency-doubled crystal?
By combining with a frequency-doubled crystal, all-solid-state lasers with near-infrared, green, blue, and ultraviolet wavelengths can be realized.
What are the applications of Nd: YVO4 crystal?
Nd: YVO4 crystal is commonly used in diode pumped solid lasers and as a seed laser source.
