Stradus® 561‐50 Diode Laser Module
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2015
Description
The Stradus® 561 laser module, developed by Vortran Laser Technology, Inc., stands at the forefront of laser technology with its fully integrated, plug-and-play design. This self-contained laser module is engineered for high performance, offering a unique combination of patented sealed optical cavity and cutting-edge electronics. These features ensure unmatched power stability, beam pointing precision, and minimal noise across various conditions of time and temperature.
Ideal for a range of applications, the Stradus® 561 is designed to meet the rigorous demands of medical, biomedical, and industrial fields. One of the standout features of the Stradus® 561 is its user-friendly interface, facilitated by Vortran’s Graphical User Interface (GUI) software. This intuitive software enables users to control and monitor the laser module remotely via USB or RS-232 connections, providing flexibility and ease of use.
The module’s compact and self-contained design eliminates the need for an additional controller, simplifying integration into existing systems while maintaining excellent beam quality and low noise output. Vortran Laser Technology, Inc. is committed to continuous improvement, ensuring that the Stradus® 561 remains a reliable and cutting-edge solution for professionals requiring precision and stability in laser technology.
With a focus on quality and compliance, the Stradus® 561 is CE Mark Certified and adheres to RoHS standards in both the EU and China. This dedication to excellence makes the Stradus® 561 an indispensable tool for those seeking superior performance and reliability in laser applications.
Stradus® 561‐50 Diode Laser Module
Specifications |
|
---|---|
Center Wavelength: | 0.561 um |
Output Power: | 50 mW |
Spatial Mode: | TEM 00 |
Beam Diameter: | ~0.7 mm (1/e^2) |
Beam Divergence: | ~1.0 mrad |
M² (typical): | < 1.1 |
Beam Circularity: | > 90% |
Power Stability (over 24 Hours): | < 0.5% |
Polarization Orientation: | Vertical ±2⁰ |
Polarization Extinction Ratio: | >100:1 |
Input Power (Head): | 12V DC, 2.0A (max) |
Input Power (Control Box): | 90‐250 VAC, 50/60Hz |
Storage Temperature: | -10⁰C to +60⁰C |
Operating Temperature: | +10⁰C to +45⁰C |
Laser Head Weight: | 223g |
Communication: | Mini‐USB and RS‐232 |
CDRH Class: | Class IIIb |
ESD Protection: | Class 4 |
EU Compliance: | CE Mark Certified with control box |
RoHS Compliance: | EU and China |
Features
- Wavelength: 561 ± 2 nm
- Power Output: 50 mW (‐0%, +10%)
- Spatial Mode: TEM 00
- Beam Diameter: ~0.7 mm (1/e²)
- Beam Divergence: ~1.0 mrad
- M² (typical): < 1.1
- Beam Circularity: > 90%
- Beam Centration: < 0.5 mm
- Beam Alignment: < 5 mrad
- Pointing Stability: < 10 µrad/°C
- Power Stability (over 24 hours): < 0.5%
- Polarization Orientation: Vertical ±2°
- Polarization Extinction Ratio: >100:1
- RMS Noise (10Hz to 10MHz): <0.1%
- Digital Modulation: 10 MHz
- Digital Rise Time: < 12 nsec
Applications
- Biomedical Research & Imaging: Ideal for fluorescence excitation in microscopy and imaging systems requiring stable 561 nm illumination.
- Flow Cytometry: Provides reliable excitation for precise cell analysis in life science laboratories.
- Industrial Alignment & Inspection: Suitable for precision alignment and optical inspection tasks.
- Scientific Instrumentation: Integrates into OEM and laboratory systems demanding high stability and low noise laser sources.
Frequently Asked Questions
The input power required for the Stradus 561 laser module is 12V DC, 2.0A (max) for the head and 90‐250 VAC, 50/60Hz for the control box.
The polarization extinction ratio of the Stradus 561 laser module is greater than 100:1.
The beam diameter of the Stradus 561 laser module is approximately 0.7 mm.
The power output of the Stradus 561 laser module is 50 (‐0%, +10%) mW.
The wavelength of the Stradus 561 laser module is 561 ± 2nm.
