Description
Utilizes small, state of the art UV-C LEDs which provide pathogen reduction without the use of harmful chemicals of mercury-based UV lamps.
PearlLab Beam UV Research Tools for Disinfection
Specifications
Emission Spectral Range: | 255 – 365 nm |
---|---|
Application: | Water Purification and Disinfection, Liquid Disinfection, Surface Disinfection, Document Analysis, Printing, Forensic Analysis, Blood Detection, Polymerization, Industrial, Commercial, Research and Development, Miscellaneous, Wafer UV Flood Exposure, Microscopy, Vision |
Irradiance Range (model Dependent): | 0.05 - 13 mW/cm2 |
Features
- Features UVinaire: Replaceable UV LED lamp module with up to 3 selectable wavelengths. Stabilized UV output through advanced cooling design.
- Optional Stage and Stand accessory allows for easy access to a Petri dish as well as simple and repeatable Petri Factor measurement.
- Optional UV Intensity sensor and radiometer allow measurement in the 250-400 nm range and provide data and trends.
Applications
UV Dose (UV Fluence) response for liquids and surfaces
- Photopolymerization of materials
- Wavelength effect studies
- Fluorescent slides
Frequently Asked Questions
Is the PearlLab Beam UV Research Tool suitable for lab or field use?
Yes, the PearlLab Beam UV Research Tool is suitable for both lab and field use.
What accessories are available for the PearlLab Beam UV Research Tool?
The accessories available for the PearlLab Beam UV Research Tool include a Stage and Stand, Intensity Sensor & Radiometer, Carrying Case, UVinaire Collimating Tube, PearlLab Beam Stand, Petri Dish, Radiometer, and XY Stage.
What are the features of the PearlLab Beam UV Research Tool?
The PearlLab Beam UV Research Tool features a UVinaire: Replaceable UV LED lamp module with up to 3 selectable wavelengths, stabilized UV output through advanced cooling design, and optional Stage and Stand accessory allows for easy access to a Petri dish as well as simple and repeatable Petri Factor measurement. It also has an optional UV Intensity sensor and radiometer that allow measurement in the 250-400 nm range and provide data and trends.
What are the specifications of the PearlLab Beam UV Research Tool?
The PearlLab Beam UV Research Tool has an operating temperature of 0-35o C [32-95o F], a lamp life of over 1,000 hours, and weighs approximately 1.6 kg [3.5 lbs]. It has an input power of 110-240 V AC and comes with a power supply model number. The wavelengths range from 255-365 nm and the irradiance ranges from 0.05-13 mW/cm2.
What is the PearlLab Beam UV Research Tool used for?
The PearlLab Beam UV Research Tool is used for pathogen reduction without the use of harmful chemicals or mercury-based UV lamps. It is also used for UV Dose (UV Fluence) response for liquids and surfaces, photopolymerization of materials, wavelength effect studies, and fluorescent slides.
