Free Space Optical Isolator Customized Quantum Optics Application

Name: Free Space Optical Isolator Customized Quantum Optics Application
Brand: CSRayzer Optical Technology
Availability: InStock

Description

CSRayzer's free-space optical isolator is made of magneto-optical crystal with high Wilder constant and magnet with high magnetic field strength. It is a device that only allows one-way light to pass and prevents reverse light from entering the front-end optical system. It has the characteristics of high isolation, low loss and high power resistance. According to the needs of users, we can provide a variety of wavelength isolators, such as 405nm, 532nm, 633nm, 780nm, 800nm, 852nm, 980nm, 1064nm, etc., and the aperture of light can be provided as required, such as 1mm, 2mm, 3mm, 5mm, etc.

Specifications

Type Of The Device:	Isolator
Operating Wavelength:	405 nm
Max Power:	30 W
Min Isolation:	30 dB
Transmission @λc:	≥90 %
Clear Aperture:	1mm, 2mm, 3mm, 5mm, etc required

Download Data Sheet

Features

High isolation

Low loss

High power resistance

Applications

Laser Systems: Enhance the performance of laser systems by preventing back reflections that can cause instability or damage.

Optical Communication: Improve signal quality in optical communication systems by ensuring unidirectional light propagation.

Scientific Research: Utilize in laboratories for experiments requiring precise control of light direction and isolation.

Medical Equipment: Integrate into medical laser systems to protect sensitive components from back reflections.

Industrial Applications: Use in industrial laser systems for cutting, welding, and material processing to ensure consistent performance.

Optical Testing: Employ in optical testing setups to isolate components and prevent interference from reflected light.

Photonics Research: Support photonics research by providing reliable isolation for experiments involving light manipulation.

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

CSRayzer Optical Technology

On FindLight:

since 2020

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is a free-space optical isolator?

A free-space optical isolator is a device made of magneto-optical crystal and a magnet that allows light to pass in one direction while preventing reverse light from entering the front-end optical system.

What are the key features of CSRayzer's free-space optical isolator?

The key features include high isolation, low loss, and high power resistance. It can be customized for various wavelengths and light apertures.

What wavelengths are available for CSRayzer's optical isolators?

Available wavelengths include 405nm, 532nm, 633nm, 780nm, 800nm, 852nm, 980nm, 1064nm, and others.

What is the peak isolation provided by these optical isolators?

The peak isolation provided by these optical isolators is 30dB.

What is the transmission rate of the optical isolators?

The transmission rate of the optical isolators is typically ≥90% or ≥92%, depending on the model.

What is the peak power damage threshold for these isolators?

The peak power damage threshold for these isolators is 10J/cm².

Can the aperture size of the optical isolator be customized?

Yes, the aperture size can be customized as required, with options such as 1mm, 2mm, 3mm, and 5mm.
