The 1064nm TGG Based High Power Optical Circulator-100W Series from DK Photonics is engineered to deliver exceptional performance in demanding optical systems. Utilizing Terbium Gallium Garnet (TGG) as the core material, this circulator is specifically designed for high-power applications, offering robust operation at power levels up to 100W. Its advanced design ensures efficient routing of optical signals, directing light from Port 1 to Port 2 and from Port 2 to Port 3 with minimal loss and high reliability.

This optical circulator stands out for its low insertion loss and high isolation, which are critical for maintaining signal integrity in high-power fiber laser and amplifier systems. The device exhibits excellent return loss and low polarization dependent loss (PDL), making it suitable for both polarization-maintaining (PM) and non-PM configurations. Its construction also provides outstanding temperature stability and environmental resilience, ensuring consistent performance even in challenging operational conditions.

Ideal for integration into high-power fiber lasers, amplifiers, pump laser sources, and precision test and measurement instrumentation, the 1064nm TGG Based High Power Optical Circulator is a versatile solution for advanced photonics applications. The circulator can be customized to meet specific requirements, including fiber type, pigtail length, and wavelength, allowing seamless adaptation to a wide range of system architectures.

This flexibility, combined with its high power handling and reliability, makes it a preferred choice for professionals seeking robust and efficient optical routing in high-performance environments.

1064nm High Power Polarization Insensitive Circulator

Visit the DK Photonics Store

Specifications

Type Of The Device: Circulator
Operating Wavelength: 1064 nm
Max Power: 10 W
Min Isolation: 22 dB
Insertion Loss (IL): Low
Isolation: High
Return Loss (RL): High
Polarization Dependent Loss (PDL): Low
Polarization Mode Dispersion (PMD): Low
Fiber Type: PM and Non-PM available
Fiber Pigtail Length: 1.0 m (example)
Fiber Core/Cladding: 25/250 μm (example)
Numerical Aperture (NA): 0.065/0.46 (example)

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • High Power Handling up to 100W: Engineered for robust performance in high-power fiber laser and amplifier systems.
  • Low Insertion Loss: Minimizes signal attenuation for maximum transmission efficiency.
  • High Isolation: Ensures excellent channel separation, reducing signal cross-talk and back-reflection.
  • Polarization Maintaining (PM) and Non-PM Options: Available in both PM and non-PM configurations to suit diverse application needs.
  • Customizable Fiber Types: Supports a wide range of fiber types and pigtail lengths for tailored integration.
  • Excellent Temperature Stability: Maintains stable performance across a broad temperature range, ideal for demanding environments.
  • High Reliability and Environmental Stability: Designed for long-term operation with consistent performance in various conditions.
  • Low Polarization Dependent Loss (PDL) and Low Polarization Mode Dispersion (PMD): Guarantees signal integrity for precision applications.
  • High Return Loss: Reduces unwanted reflections, protecting sensitive laser sources and measurement equipment.
  • TGG (Terbium Gallium Garnet) Based Design: Utilizes advanced TGG crystal technology for superior optical performance and power handling.
  • 3-Port Circulator Functionality: Efficiently routes optical signals from Port 1 to Port 2 and Port 2 to Port 3, supporting complex optical networks.
  • Connector and Bare Fiber Options: Available with or without connectors; high-power applications supported via fiber splicing.
  • Ideal for Multiple Applications: Perfect for high-power fiber lasers, fiber amplifiers, pump laser sources, test and measurement, and instrumentation.
  • Custom Solutions Available: DK Photonics offers tailored designs for unique wavelength, power, and fiber requirements.

Applications

  • High Power Fiber Laser Systems
    Enables efficient routing and isolation of optical signals in high power fiber laser setups, supporting industrial material processing, cutting, welding, and micromachining applications.
  • High Power Fiber Amplifiers
    Essential for signal direction and isolation in high power fiber amplifier modules, ensuring stable amplification and protection of sensitive components.
  • Pump Laser Source Management
    Facilitates the integration and management of high power pump lasers in fiber laser and amplifier systems, improving overall system efficiency and reliability.
  • Test and Measurement Equipment
    Used in advanced optical test benches and measurement setups to direct high power laser signals with minimal loss and high isolation, ensuring accurate results.
  • Optical Instrumentation
    Supports a wide range of scientific and industrial optical instruments requiring precise signal routing, high power handling, and environmental stability.
  • Optical Sensing Systems
    Ideal for distributed fiber optic sensing applications, including structural health monitoring and environmental sensing, where high power and low loss are critical.
  • Nonlinear Optics Experiments
    Enables safe and efficient management of high power beams in nonlinear optics research, such as frequency conversion and supercontinuum generation.
  • Quantum Optics and Communication
    Provides reliable signal routing in quantum communication setups and experiments requiring high isolation and low insertion loss at 1064nm.
  • Medical Laser Systems
    Integrated into medical laser devices for surgery, dermatology, and ophthalmology, where high power handling and signal integrity are essential.
  • Laser Micromachining and Precision Manufacturing
    Used in precision laser processing systems for electronics, semiconductor, and microfabrication industries, ensuring high performance and reliability.

Frequently Asked Questions

What is the DK Photonics 1064nm TGG Based High Power Optical Circulator-100W Series?
The DK Photonics 1064nm TGG Based High Power Optical Circulator-100W Series is a high-performance fiber optic component designed to route optical signals between three ports with minimal loss and high isolation. It is optimized for high power handling up to 100W and is suitable for use in high power fiber lasers, amplifiers, pump laser sources, and test and measurement instrumentation.
What are the key features of the 1064nm TGG Based High Power Optical Circulator?
Key features include low insertion loss, high power handling (up to 100W), high isolation, high reliability, excellent temperature stability, and availability in both polarization-maintaining (PM) and non-PM versions. The circulator can also be customized for different fiber types and connector options.
What applications are suitable for the DK Photonics high power optical circulator?
This optical circulator is ideal for high power fiber lasers, high power fiber amplifiers, pump laser sources, test and measurement setups, and other instrumentation requiring efficient signal routing and high power handling at 1064nm.
How does the 1064nm TGG Based Optical Circulator work?
The circulator routes incoming optical signals from Port 1 to Port 2, and signals entering Port 2 are directed to Port 3. This non-reciprocal routing is achieved using a TGG (Terbium Gallium Garnet) crystal, which provides high isolation and low insertion loss, making it suitable for demanding high power applications.
Can the DK Photonics high power optical circulator be customized?
Yes, DK Photonics offers customization for their optical circulators, including different fiber types, connector options, wavelengths, and power handling capabilities. Customers can provide detailed specifications to receive a tailored solution for their application.
What is the difference between PM and non-PM versions of the optical circulator?
PM (Polarization Maintaining) versions maintain the polarization state of the transmitted light, which is crucial for certain laser and sensing applications. Non-PM versions do not maintain polarization but may be suitable for less demanding applications. The circulator can be ordered in either configuration based on application needs.
What should I consider regarding connectors and fiber splicing for high power operation?
For high power operation, it is recommended to use spliced fibers rather than connectors, as connectors are only rated for low power (up to 2W) and are primarily used for performance testing. Using connectors at high power levels can result in damage or degraded performance.

Got more questions? Use the inquiry form to ask the supplier directly.
