Introducing thej-BendAble HT Fiber, a cutting-edge optical fiber solution designed for superior performance in demanding environments. This fiber is engineered to deliver exceptional bending performance, minimizing macrobending loss and ensuring reliable data transmission even in challenging conditions. With a bend-induced attenuation specification of ≤ 0.1 dB at 1625 nm for 100 turns at a 30 mm radius, this fiber is ideal for applications where space constraints and tight bends are a concern.

The optical performance of the j-BendAble HT Fiber is unmatched, featuring an attenuation coefficient of ≤ 0.36 dB/km at 1310 nm and ≤ 0.25 dB/km at 1550 nm. The mode field diameter is precisely controlled at 9.2 ± 0.4 µm for 1310 nm and 10.4 ± 0.5 µm for 1550 nm, ensuring optimal light propagation and minimal signal loss. The fiber's cut-off wavelength ranges from 1180 to 1330 nm, providing flexibility for various optical network designs.

Geometrically, the j-BendAble HT Fiber is crafted with precision, featuring a core/clad concentricity error of ≤ 0.8 µm and a cladding diameter of 125.0 ± 1.0 µm. The cladding non-circularity is kept to ≤ 1.0%, and the coating diameter is maintained at 245 ± 10 µm, ensuring consistent performance and ease of handling. The fiber is available in lengths ranging from 4.4 to 50.4 km, catering to diverse project requirements.

Mechanically robust, the fiber undergoes a proof-test level of ≥ 100 kpsi, ensuring durability and reliability under stress. The typical coating strip force ranges from 2 to 3 N, facilitating easy installation and maintenance. The high-temperature acrylate coating material is designed to withstand extreme conditions, with an operating temperature range from -60 to +200°C. This makes the j-BendAble HT Fiber suitable for both short-term and long-term deployments in harsh environments.

For ordering the j-BendAble HT Fiber, please contact us with your specific requirements, including fiber type, quantity, desired ship date, reel length, and any special requests. Our team at j-fiber GmbH is committed to providing high-quality optical fiber solutions tailored to your needs.
