Description
Coractive’s SM-Raman-P is a single-mode fiber specifically designed for applications that require Raman gain
efficiency. This fiber offers good overall performance, low splice loss and can provide gain at any wavelength
between 1100 nm and 1700 nm.
SM-Raman-P
Specifications
| Mode Field Diameter (MFD): | 6.2 um |
|---|---|
| Wavelength Range: | 1100 – 1700 nm |
| Cable Length: | Not Specified |
| Fiber Core Material: | Silica |
Download Data Sheet
Features
- Small effective area
- Low splice losses
- Raman gain efficiency: between 1100nm and 1700nm
- Single-mode operation
Applications
Telecom
Frequently Asked Questions
What is the SM-Raman-P fiber used for?
The SM-Raman-P fiber is specifically designed for applications that require Raman gain efficiency.
What are the features of the SM-Raman-P fiber?
The SM-Raman-P fiber has a small effective area, low splice losses, and can provide gain at any wavelength between 1100 nm and 1700 nm.
What is the numerical aperture of the SM-Raman-P fiber core?
The numerical aperture of the SM-Raman-P fiber core is 0.18 ± 0.02.
What is the cutoff wavelength of the SM-Raman-P fiber?
The cutoff wavelength of the SM-Raman-P fiber is 850 ± 50 nm.
What is the operating temperature range for the SM-Raman-P fiber?
The operating temperature range for the SM-Raman-P fiber is 0°C to 70°C.
