Description
Discover the precision and innovation of our glass fibers, meticulously crafted for infrared (IR) applications. At the heart of these fibers is pure fused silica glass, renowned for its low OH content and consistent refractive index across the entire diameter. This makes them ideal for use in a broad wavelength range from 400 nm to 2400 nm, covering both visible (VIS) and infrared spectrums. These fibers are expertly coated with materials such as acrylate, silicone, or polyimide, ensuring durability and adaptability across various environments.
Our step-index multimode fibers are a testament to versatility and reliability. They serve not only in optical data transmission but also play a crucial role in sensor technology, spectroscopy, medical technology, and laser applications. The fibers are available in a range of core diameters, from 40 μm to 200 μm, and are designed to maintain a uniform refractive index, enhancing their performance across diverse applications.
Each fiber is available with different coating options to meet specific temperature and environmental requirements. The acrylate coating, for instance, offers a temperature range of -40 °C to 85 °C, while the polyimide coating extends from -190 °C to 385 °C, providing solutions for both standard and extreme conditions. Additionally, fibers with coatings and jackets are available, offering further protection and customization options, including a variety of colors for easy identification and integration into existing systems.
Our fibers are designed with flexibility in mind, featuring short-term and long-term bending radii to accommodate dynamic applications. Whether used in high-tech medical devices or advanced communication systems, these fibers deliver exceptional performance and reliability. Choose our fibers for your next project and experience the cutting-edge technology and quality that LEONI Fiber Optics is known for.
Tefzel Silicone-Jacket Coated Multimode Fiber – 84810177N
Specifications |
|
|---|---|
| Core Diameter: | 600 um |
| Wavelength Range: | 400 – 2400 nm |
| Fiber Core Material: | Silica |
| Fiber Length: | Custom |
Features
- High-Quality Material: The core of the glass fibers is made from pure fused silica glass with low OH content, ensuring a uniform refractive index across the entire diameter.
- Broad Wavelength Range: These fibers are suitable for use in wavelengths ranging from 400 nm to 2400 nm (VIS-IR).
- Versatile Applications: Ideal for optical data transmission, sensor technology, spectroscopy, medical technology, and laser applications.
- Step-Index Multimode: Available in multiple core diameters (40 µm to 200 µm) with corresponding cladding diameters.
- Flexible Bending Radius: Short-term bending radius is 100 times the clad radius; long-term bending radius is 600 times the clad radius.
- Color Options: Jackets are available in various colors, including black, blue, transparent, yellow, red, and white.
- Special Coating: ORMOCER® coating is available for continuous use at temperatures up to 200 °C.
Applications
- Optical Data Transmission: These fibers are ideal for transmitting optical data across a wide range of wavelengths from 400 nm to 2400 nm (VIS-IR).
- Sensor Technology: Suitable for various sensor applications due to their reliable performance and broad wavelength range.
- Spectroscopy: Used in spectroscopy for analyzing the spectral properties of light over a broad range.
- Medical Technology: Applicable in medical technology for procedures requiring precise light transmission.
- Laser Applications: Utilized in laser applications where high precision and reliability are critical.
Frequently Asked Questions
The core material of the Tefzel Silicone-Jacket Coated Multimode Fiber is pure fused silica glass with low OH content and uniform refractive index across the entire diameter.
The multimode fibers are used in optical data transmission, sensor technology, spectroscopy, medical technology, and laser applications.
The temperature range for the fibers with coating and jacket is -40 °C to 150 °C.
The fibers are used in a wavelength range from 400 nm to 2400 nm (VIS-IR).
The short-term bending radius for the fibers is 100 x clad radius.
