Multistrand POF Cable for Data Transmission and Lighting
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
Jiangsu TX Plastic Optical Fibers Co.,Ltd -
On FindLight:
since 2022
Description
Introducing our premium range of Multistrand PMMA Optical Cables, designed to meet the highest standards of quality and performance. These optical cables are crafted with precision to ensure optimal light transmission, making them an ideal choice for a variety of applications. The cables are available in different outer diameters, ranging from 3.0 mm to 15.0 mm, and are encased in durable PVC jacketing. The transparent and black PVC options provide flexibility in design and installation, catering to diverse aesthetic and functional requirements.
Our optical cables are engineered to operate efficiently across a wide temperature range of -50℃ to +70℃, ensuring reliability in both extreme cold and hot environments. With an attenuation rate of ≤250 dB/Km, these cables maintain excellent signal integrity over long distances. The cables are available in various spool lengths, with options up to 900 meters, allowing for seamless integration into large-scale projects.
Manufactured by Jiangsu TX Plastic Optical Fibers Co., Ltd, these multistrand PMMA optical cables are perfect for illuminating historical relics, jewelry, furniture, historic buildings, and more. They are also suitable for use in food cabinets and environments where safety is paramount, such as flammable and explosive circumstances. Our commitment to quality ensures that each cable delivers exceptional performance, making them a trusted choice for professionals worldwide.
Multistrand POF Cable for Data Transmission and Lighting
Specifications |
|
|---|---|
| Core Diameter: | 0.25 um |
| Wavelength Range: | 530 – 650 um |
| Fiber Core Material: | Plastic |
| Cable Length: | 2500 m |
| Fiber Diameter: | 0.25mm,0.5mm,0.75mm,1.0mm... |
| Fiber Number: | 1 core,2 core,3 core,8 core,12core,etc |
| Application: | data transmission and lighting |
| Inner Fiber Material: | PMMA |
| Outer Jacket Material: | PVC/PE/TPU/TPE |
Features
- Product Code: Multiple options available, including TX-FL0750-33.0±0.2, TX-FL1000-33.8±0.2, and more.
- Outer Diameter: Ranges from 3.0 mm to 15.0 mm, depending on the product variant.
- Jacketing Materials: Available in Transparent PVC and Black PVC.
- Attenuation: ≤250 dB/Km, ensuring minimal signal loss.
- Numerical Aperture (N.A.): 0.5, providing efficient light transmission.
- Operating Temperature: Suitable for environments ranging from -50℃ to +70℃.
- Spool Length: Options include 100 m, 500 m, and 900 m, catering to different project needs.
- Specification: Multistrand PMMA optical cable, ideal for various lighting applications.
Applications
- Historical and Cultural Lighting: Illuminates relics, monuments, and museum displays.
- Decorative Furniture Lighting: Ideal for aesthetic enhancement of cabinets and interiors.
- Architectural Accents: Lights up historic buildings, décor, and specialty installations.
- Jewelry and Display Cases: Provides focused illumination without heat damage.
- Hazardous Areas: Safe for use in flammable or explosive environments.
Frequently Asked Questions
The Multistrand POF cable is certified with UL, RoHS, and Reach certifications.
The Multistrand POF cable has features such as better anti-crunch, anti-stretch, anti-grinding, and anti-aging performances. It also has a unique loose jacket for easy peeling off and creates varied multi-strand cable end-lighting effects.
The Multistrand POF cable is suitable for applications such as star effect lighting for ceilings and swimming pool bottoms, artistic adornment in graphical and 3D artistic design, museum showcases and jewelry display, lighting in dangerous places like oil depots, interior fiber optic light decoration in entertainment venues, decorative lighting in parks and fairgrounds, and underground lighting.
The Multistrand POF cable can operate within a temperature range of -50℃ to +70℃.
The outer diameter of the Multistrand POF cable varies depending on the product code, ranging from 3.0mm to 15.0mm. The jacketing material is black PVC for most products, while some have a transparent PVC jacket.
