FPYL-355-XXT Ultra Violet CW DPSS Laser

Visit the Frankfurt Laser Company Store

Specifications

Wavelength: 355 nm
Max Output Power: 30 mW
Cooling Method: Air-Cooled
Tunability: Fixed Wavelength
Control Interface: Other (not specified)
Transverse Mode: Near TEM00
Power Stability (RMS, Over 4 Hours): <5 %
Warm-up Time: <10 minutes
M² Factor: <1.5
Eam Diameter At The Aperture (1/e²): <1.2 mm
Beam Divergence (FW): <1.5 mrad
Pointing Stability After Warm-up: <0.05 mrad
Polarization Ratio: >50:1
Beam Height From Base Plate: 27.4 mm
Modulation (optional): TTL/Analog
Operating Temperature: 10-35 °C

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Wavelength: 355±1 nm
  • Output Power Range: 1-30 mW
  • Transverse Mode: Near TEM00
  • Operating Mode: CW
  • Power Stability: <5%, <10%* (RMS, over 4 hours)
  • Warm-up Time: <10 minutes
  • M² Factor: <1.5
  • Beam Diameter at the Aperture (1/e²): <1.2 mm
  • Beam Divergence (FW): <1.5 mrad
  • Pointing Stability after Warm-up: <0.05 mrad
  • Polarization Ratio: >50:1
  • Beam Height from Base Plate: 27.4 mm
  • Modulation: TTL/Analog* (1Hz-1kHz, 1kHz-10kHz, 10kHz-30kHz)**
  • Operating Temperature: 10-35°C

Applications

  • Laser microfabrication
  • Micromachining
  • Semiconductor inspection
  • Fluorescence imaging
  • Photolithography
  • Raman spectroscopy
  • Laser-induced fluorescence
  • Laser marking
  • Optical trapping
  • Biological and chemical analysis
