Low Noise Tunable Laser PPCL700
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2018
Description
The PPCL700 tunable laser from Pure Photonics represents a cutting-edge solution in the realm of full-band tunable lasers. Designed with precision and versatility in mind, this laser is engineered to deliver exceptionally narrow linewidths of approximately 15 kHz. This feature, combined with significantly reduced low-frequency amplitude modulation (AM) and frequency modulation (FM) noise, makes it an ideal choice for high-performance applications.
The laser's ability to access any desired frequency set-point within the C-band or L-band further enhances its adaptability, offering output power settings ranging from as low as 7dBm to as high as 17dBm, depending on the specific requirements. Built upon the robust foundation of the Neophotonics telecom-grade tunable laser, the PPCL700 incorporates an advanced optical engine alongside a newly optimized electronics platform.
This integration results in superior noise performance and introduces a suite of additional control features, including sweeps, jumps, amplitude modulation, and frequency modulation. These enhancements are particularly beneficial for applications demanding high signal-to-noise ratios, such as sensing and test and measurement (T&M) environments. In its low-noise operational mode, the PPCL700 effectively disables its control loops, maintaining a stable and 'frozen' state. To ensure tunability and flexibility in this mode, Pure Photonics has developed specialized control schemes.
These schemes enable functionalities such as clean frequency sweeps, frequency modulation with a bandwidth of 100 kHz and an amplitude of up to 100 MHz, and amplitude modulation with a bandwidth of 1 MHz. Additional features include the ability to perform clean frequency jumps within two seconds, rapid full-range frequency scans, and integrated data acquisition capabilities. With these features, the PPCL700 stands out as a versatile and high-performance tool for a range of demanding applications.
Low Noise Tunable Laser PPCL700
Specifications |
|
|---|---|
| Center Wavelegth: | 1527 nm |
| Tuning Range: | 38 – 60 nm |
| Sweep Speed: | 0.1 nm/sec |
| Power: | 17 dBm |
| Linewidth: | 15 kHz |
| Frequency Sweep Range: | 50 GHz to 250 GHz |
| Frequency Modulation Bandwidth: | 100 kHz |
| Frequency Modulation Amplitude: | up to 100 MHz |
| Amplitude Modulation Bandwidth: | 1 MHz |
| Low-pass Filter: | 200 kHz |
Features
- Full-Band Tunable Laser: Access any desired frequency set-point in both the C-band and L-band, ensuring versatile application possibilities.
- Narrow Linewidth: Features a very narrow linewidth of approximately 15 kHz, providing high precision and clarity in laser applications.
- Adjustable Output Power: Output power ranges from as low as 7dBm to as high as 17dBm (optional), allowing for flexibility in power requirements.
- Low Noise Performance: Significantly reduced low-frequency AM and FM noise, ideal for high Signal-to-Noise-Ratio (SNR) applications.
- Advanced Control Features: Includes sweeps, jumps, Amplitude Modulation (AM), and Frequency Modulation (FM) for enhanced control and functionality.
- High SNR Applications: Designed for use in sensing and Test & Measurement (T&M) environments where high SNR is critical.
- Clean Sweep: Achieve a repeating frequency sweep of 50GHz up to 250GHz for comprehensive frequency analysis.
- Frequency Modulation: Offers a bandwidth of 100kHz and an amplitude of up to 100MHz, suitable for varied modulation needs.
- Amplitude Modulation: Provides a bandwidth of 1MHz, supporting diverse amplitude modulation requirements.
- Clean Jump and Scan: Quickly jump to any frequency within 2 seconds or scan the full frequency range as fast as within 10 seconds.
- Integrated DAQ Functionality: Clean Measurement feature includes integrated Data Acquisition (DAQ) capabilities for seamless operation.
- Low RIN: Reduced noise with a 200kHz low-pass filter (note: not compatible with AM), ensuring clearer signal quality.
- Regular Firmware and GUI Updates: Stay updated with regular firmware and GUI updates available on the Pure Photonics website, with backward compatibility when possible.
Applications
- Optical Sensing: Ideal for distributed and point sensing requiring high SNR and stability.
- Test & Measurement: Suited for high-precision optical characterization systems.
- Metrology: Enables frequency-stable sources for scientific and industrial measurements.
- Coherent Communication Testing: Provides a tunable low-noise source for R&D and validation.
