Thumbnail of Narrow Band Tunable Laser Module with a SOA photo 1

Description

Optochip's OC2XX Series tunable laser is a DBR laser with a semiconductor optical amplifier (SOA). Its wavelength can be tuned continuously a tuned to ITU channel grids. injection current to SOA can be used to level the power over the tuning range of applications, as well as to produce pulse.

Narrow Band Tunable Laser Module with a SOA

Visit the OptoChip Optoelectronics Ltd. Store

Specifications

Center Wavelegth: 1550 nm
Tuning Range: 1540 – 1550 nm
Sweep Speed: 10000 nm/sec
Power: 10 dBm
Optical Output Power: 30 mW
Side-mode Suppression Ratio: > 40 dB
Wavelength Tuning Range: 8-10 nm
Storage Temperature: -40 to 85 °C
Relative Humidity: 0 to 85 %

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • 14 PIN Butterfly Package
  • Optical output power
  • High side-mode suppression ratio>40dB
  • Wavelength adjust flexibly
  • Qualified as per intent of Telcordia GR
  • RoHS

Applications

  • DWDM transmission systems
  • Tunable DWDM transponders and transceivers
  • Dynamic provisioning and wavelength routing in DWDM systems
  • Test and measurement
  • Optical Fiber Sensing
  • Pulsed applications for Weak Fiber Bragg Grating Interrogators

Frequently Asked Questions

What is the model of the tunable laser module?
The model of the tunable laser module is the OC2XX Series.
What type of laser is used in the OC2XX Series?
The OC2XX Series uses a DBR laser with a semiconductor optical amplifier (SOA).
What is the optical output power of the OC2XX Series tunable laser?
The optical output power of the OC2XX Series tunable laser is 30 mW.
What is the side-mode suppression ratio of the tunable laser?
The side-mode suppression ratio of the tunable laser is greater than 40 dB.
What is the wavelength tuning range of the OC2XX Series?
The wavelength tuning range of the OC2XX Series is 8-10 nm.
What are the applications of the OC2XX Series tunable laser?
The applications include DWDM transmission systems, tunable DWDM transponders and transceivers, dynamic provisioning and wavelength routing in DWDM systems, test and measurement, and optical fiber sensing.
What is the operating temperature range for the OC2XX Series?
The storage temperature range for the OC2XX Series is from -40°C to 85°C.

Got more questions? Use the inquiry form to ask the supplier directly.
