Description

The XQ5120 Multi-mode Test Light Source from Shenzhen Oscom Technology Co., Ltd. is a cutting-edge solution designed for precision and reliability in optical testing environments. Independently developed by OSCOM Technology, this light source leverages advanced LED and VCSEL technologies to deliver consistent and accurate results. The integration of automatic temperature control (ATC), automatic power control (APC), and RS232C communication control ensures that the XQ5120 maintains optimal performance under varying conditions.

Engineered to provide 1/2/3/4-channel benchtop light sources, the XQ5120 is versatile and adaptable to a range of testing needs. Its typical application wavelengths, such as 850nm and 1310nm, make it suitable for a variety of optical device manufacturing and testing scenarios. The XQ5120 is not only stable and reliable but also user-friendly, making it an ideal choice for professionals in the optical industry.

With its robust design and advanced features, the XQ5120 is perfectly suited for environments that demand high precision and reliability. Whether you are involved in optical fiber communication tests, optical fiber sensing tests, or the production and testing of optical fiber devices and modules, the XQ5120 provides the performance and ease of use that professionals require. Its compact dimensions and lightweight design further enhance its appeal, making it a practical addition to any optical testing setup.

Multi-mode Test Light Source 850nm and 1310nm XQ5120

Specifications

Center Wavelength: 850 nm
Average Power: 1.0E-5 W
Center Wavelength: 850nm, 1310nm
Spectrum Width: ≥30nm(-3dB),≤5nm(-3dB)
Output Optical Power: ≥10uW、≥0dBm
Fiber Type: 50/125、62.5/125、105/125um、customization
Output-attenuation: Step adjustment/Continuous adjustment
Short-term Stability (15 Minutes): <0.01dB
Long-term Stability (8 Hours): <0.05dB
Optical Fiber Connector: FC/UPC、FC/APC、ST/APC、SC/APC
Communication Interface: RS232C/No
Operating Environment Temperature: 0-40℃
Operating Environment Humidity: 5-95%RH
Storage Temperature: -20 - +70℃
Operating Power Supply: AC100-240V/50-60Hz/3A
Dimensions (L×W×H): 256×254×89/332×225×93mm
Weight: 2.5Kg
Bandwidth: ±20nm

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Multi-mode Test Light Source: The XQ5120 is a versatile test light source designed by OSCOM Technology, utilizing LED and VCSEL devices for emission.
  • Advanced Technology Integration: Features automatic temperature control (ATC), automatic power control (APC), and RS232C communication control for enhanced performance.
  • Multiple Channel Options: Offers 1/2/3/4-channel benchtop light source configurations with typical application wavelengths of 850nm and 1310nm.
  • Stable and Reliable: Ensures stability and reliability, making it ideal for optical device manufacturing, testing, and other applications.
  • Wide Applied Range: Suitable for optical fiber communication tests, sensing tests, device production, module production, system integration, and automatic optical test system construction.
  • Configuration and Type Selection: Customize your XQ5120 with options for light emitting device type (LED or VCSEL), operating wavelength (850nm or 1310nm), output power (0dBm or -20dBm), optical fiber type (50/125,

Applications

  • Optical Fiber Communication Test
  • Optical Fiber Sensing Test
  • Optical Fiber Device Production and Test
  • Optical Fiber Module Production Test
  • Optical Fiber Communication System Integration
  • Automatic Optical Test System Construction

Frequently Asked Questions

What is the XQ5120 Multi-mode Test Light Source?
The XQ5120 is a multi-mode test light source designed by OSCOM Technology, utilizing LED and VCSEL devices as its emission source. It integrates technologies like automatic temperature control, automatic power control, and RS232C communication control, making it suitable for optical device manufacturing, testing, and other applications.
What are the typical application wavelengths for the XQ5120?
The typical application wavelengths for the XQ5120 are 850nm and 1310nm.
What are the main applications of the XQ5120?
The XQ5120 is used for optical fiber communication tests, optical fiber sensing tests, optical fiber device production and tests, optical fiber module production tests, optical fiber communication system integration, and automatic optical test system construction.
What types of optical fiber connectors are compatible with the XQ5120?
The XQ5120 is compatible with FC/UPC, FC/APC, ST/APC, and SC/APC optical fiber connectors.
What is the operating environment for the XQ5120?
The XQ5120 operates in temperatures ranging from 0-40℃ and humidity levels from 5-95%RH.
What is the power supply requirement for the XQ5120?
The XQ5120 requires an AC power supply of 100-240V, 50-60Hz, and 3A.
